ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm

SKU: ZXI8.4D
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm
ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm

ZXI 8" High Excursion Subwoofer Quad Stacked Magnets | 600W RMS DVC 4-Ohm

SKU: ZXI8.4D

$203.95
/EACH
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
In stock

Size: 8"

8"
10"
12"
15"

Impedance: 4-Ohm

2-Ohm
4-Ohm
Quantity:

  • Key Features

    • 8" High Excursion Subwoofer
    • MAX Power: 1200 Watts
    • RMS Power: 600 Watts
    • Impedance: 4-Ohm 2" DVC
    • Quad Stacked Ferrite Magnet
    • 86dB

  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    ZXI8.4D
    Nominal Diameter
    8" / 203.2mm
    Nominal Impedance
    4 + 4 ohms
    RMS Power Handling
    600W
    Maximum Power Handling
    1200W
    Sensitivity (1w/1m)
    86dB
    Frequency Response
    25-880Hz
    Recommended Lo Pass Crossover
    90Hz

    MOTOR

    Voice Coil Diameter
    2" / 50.8mm
    Voice Coil Former Material
    Black Aluminum
    Winding Material
    CCAW
    Cone Material
    Non-Pressed Paper
    Dust Cap Material
    PPI
    Surround Material
    Foam
    Basket Material
    Aluminum
    Basket Color/Finish
    Black Sandblasted
    Magnet Material
    Ferrite
    Magnet Weight
    104 Oz (4 x 26 oz)
    Displacement Volume
    1.02L / 0.036ft3

    THIELE & SMALL PARAMETERS

    Equivalent Volume Vas
    6.75L / 0.238ft3
    Free Air Resonance Fs
    45Hz
    Mechanical Factor Qms
    5.318
    Electrical Factor Qes
    0.791
    Total Factor Qts
    0.689
    Moving Mass Mms
    87.65g
    Compliance Cms
    0.135mm/N
    Bl Factor Bl
    8.073
    Voice Coil Inductance Le
    0.476 mH
    Diaphragm Area Sd
    188.69cm2
    DC Resistance Re
    4.0+4.0 ohms
    Efficiency Bandwidth Product EBP
    58.4

    RECOMMENDED ENCLOSURES

    Sealed Internal Volume
    17L / 0.6ft3
    Sealed Box Output Response F3
    50Hz
    Ported Internal Volume
    28.3L / 1ft3
    Port Size *Square (W x H x Long)
    1.75" x 7.99" x 14.67" / 44.5 x 203 x 372.7mm
    Port Tuning Frequency FB
    35Hz
    Ported Box Output Response F3
    28Hz

    MEASUREMENTS

    Overall Diameter
    8.58" / 218mm
    Overall Depth
    6.83" / 173.5mm
    Front Mount Baffle Cutout
    7.31" / 185.8mm
    Mounting Depth
    5.51" / 140mm
    Motor Diameter
    5.27" / 134mm
    Gross Single Unit Weight
    14
    Dimensions W x L x H
    9.5 x 9.5 x 7.75
    Quantity of Units in Master Carton
    2
    Gross Master Carton Weight
    29.5
    Master Carton Dimensions W x L x H
    19.5 x 10.25 x 8.5

    Load More

  • Product Overview

    Product Overview

    DS18 ZXI8.4D

    High Excursion 8" Car Audio Subwoofer 1200W Watts 4-Ohm DVC Quad Stacked Magnets

    Experience bass like never before with DS18’s ZXI8.4D: the ultimate subwoofer for enthusiasts who crave thunderous bass!
    The ZXI subline is renowned for its high excursion capabilities, and the ZXI8.4D is no exception. This subwoofer handles wattage as high as 1200W while delivering smooth ultra-low frequency responses. The ZXI8.4D’s lower than normal FS (Resonant Frequency), allows it to excel in larger boxes with lower tuning. Whether you prefer sealed or ported boxes, the ZXI8.4D will excel in both, giving you the flexibility to optimize placement in any vehicle.
    It’s dual 4-ohm configuration and 2-inch voice coils, makes the ZXI8.4D a force to be reckoned with. Handling a staggering 600W RMS power and 1200W of MAX power, ensuring you get the full potential out of your system. The large foam surround and non-pressed paper cone work in perfect harmony, delivering crisp, smooth bass that permeates every corner of your vehicle.
    The ZXI8.4D goes beyond raw power and precision. It features a strong stamped basket adorned with show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. The quad stacked magnets on the ZXI8.4D offer a multitude of benefits, including increased magnetic field strength, improved power handling, enhanced cone control, higher excursion capabilities, greater durability, and superior heat dissipation. Not only will it impress your ears, but it will also outlast any vehicle. This subwoofer is designed to provide you with crisp and clear bass for years to come.
    Immerse yourself in bass that is both thunderous and refined, thanks to DS18's commitment to quality and innovation.
