ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm

SKU: ZXI12.4D
Ds18 ZXI High Excursion 12" Subwoofer 2000W Watts DVC 4-Ohms audio subwoofers
ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm
ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm
ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm
ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm

ZXI 12" High Excursion Subwoofer Quad Stacked Magnets | 1000W RMS DVC 4-Ohm

SKU: ZXI12.4D

$323.95
/EACH
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
In stock

Size: 12"

8"
10"
12"
15"

Impedance: 4-Ohm

2-Ohm
4-Ohm
Quantity:

  • Key Features

    • 12" High Excursion Subwoofer
    • MAX Power: 2000 Watts
    • RMS Power: 1000 Watts
    • Impedance: 4-Ohm 3" DVC
    • Quad Stacked Ferrite Magnet
    • 89.2dB

  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    ZXI12.4D
    Nominal Diameter
    12" / 304.8mm
    Nominal Impedance
    4 + 4 ohms
    RMS Power Handling
    1000W
    Maximum Power Handling
    2000W
    Sensitivity (1w/1m)
    89.2dB
    Frequency Response
    15Hz-1.8KHz
    Recommended Lo Pass Crossover
    90Hz

    MOTOR

    Voice Coil Diameter
    3" / 76.2mm
    Voice Coil Former Material
    Black Aluminum
    Winding Material
    CCAW
    Cone Material
    Non-Pressed Paper
    Dust Cap Material
    PPI
    Surround Material
    Foam
    Basket Material
    Aluminum
    Basket Color/Finish
    Black Sandblasted
    Magnet Material
    Ferrite
    Magnet Weight
    224 Oz (4 x 56 oz)
    Displacement Volume
    3.99L / 0.14 ft3

    THIELE & SMALL PARAMETERS

    Equivalent Volume Vas
    15.63L / 0.55ft3
    Free Air Resonance Fs
    31Hz
    Mechanical Factor Qms
    5.274
    Electrical Factor Qes
    0.594
    Total Factor Qts
    0.534
    Moving Mass Mms
    238.433g
    Compliance Cms
    0.065mm/N
    Bl Factor Bl
    14.55
    Voice Coil Inductance Le
    12.89 mH
    Diaphragm Area Sd
    530.93cm2
    DC Resistance Re
    4.0+4.0 ohms
    Efficiency Bandwidth Product EBP
    52.1

    RECOMMENDED ENCLOSURES

    Sealed Internal Volume
    21.2L / 0.75ft3
    Sealed Box Output Response F3
    42Hz
    Ported Internal Volume
    39.6L / 1.4ft3
    Port Size *Square (W x H x Long)
    1.23" x 12.28" x 24.35" / 32.1 x 312 x 618.4mm
    Port Tuning Frequency FB
    32Hz
    Ported Box Output Response F3
    26Hz

    MEASUREMENTS

    Overall Diameter
    12.55" / 319mm
    Overall Depth
    9.13" / 232mm
    Front Mount Baffle Cutout
    11.1" / 282mm
    Mounting Depth
    7.55" / 192mm
    Motor Diameter
    7.08" / 180mm
    Gross Single Unit Weight
    35
    Dimensions W x L x H
    14.5 x 14.75 x 11.5
    Quantity of Units in Master Carton
    1
    Gross Master Carton Weight
    35
    Master Carton Dimensions W x L x H
    14.5 x 14.75 x 11.5

    Load More

  • Product Overview

    Product Overview

    DS18 ZXI12.4D

    High Excursion 12" Car Audio Subwoofer 2000W Watts 4-Ohm DVC Quad Stacked Magnets

    Experience bass like never before with DS18’s ZXI12.4D: the ultimate subwoofer for enthusiasts who crave thunderous bass!
    The ZXI subline is renowned for its high excursion capabilities, and the ZXI12.4D is no exception. This subwoofer handles wattage as high as 2000W while delivering smooth ultra-low frequency responses. The ZXI12.4D’s lower than normal FS (Resonant Frequency), allows it to excel in larger boxes with lower tuning. Whether you prefer sealed or ported boxes, the ZXI12.4D will excel in both, giving you the flexibility to optimize placement in any vehicle.
    It’s dual 4-ohm configuration and 3-inch voice coils, makes the ZXI12.4D a force to be reckoned with. Handling a staggering 1000W RMS power and 2000W of MAX power, ensuring you get the full potential out of your system. The large foam surround and non-pressed paper cone work in perfect harmony, delivering crisp, smooth bass that permeates every corner of your vehicle.
    The ZXI12.4D goes beyond raw power and precision. It features a strong stamped basket adorned with show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. The quad stacked magnets on the ZXI12.4D offer a multitude of benefits, including increased magnetic field strength, improved power handling, enhanced cone control, higher excursion capabilities, greater durability, and superior heat dissipation. Not only will it impress your ears, but it will also outlast any vehicle. This subwoofer is designed to provide you with crisp and clear bass for years to come.
    Immerse yourself in bass that is both thunderous and refined, thanks to DS18's commitment to quality and innovation.
