SKU: ZXI6.2D

Sale price$99.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 6.5" High Excursion Subwoofer
  • MAX Power: 600 Watts
  • RMS Power: 300 Watts
  • Impedance: 2-Ohm 1.5" DVC
  • Quad Stacked Ferrite Magnet
  • 87dB
In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

6.5

6.5" DIAMETER

SUBWOOFER

SUBWOOFER

2+2 OHM

2+2 OHM

VOICE COIL 1.5

VOICE COIL 1.5"

FERRITE MAGNET

FERRITE MAGNET

HIGH EXCURSION SURROUND

HIGH EXCURSION SURROUND

DOWNLOAD THE USER MANUAL

SPECS

SKU
ZXI6.2D
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
2 + 2 ohms
RMS Power Handling
300W
Maximum Power Handling
600W
Sensitivity (1w/1m)
87dB
Frequency Response
35Hz-1.8KHz
Recommended Lo Pass Crossover
90Hz

MOTOR

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
PPI
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Black Sandblasted
Magnet Material
Ferrite
Magnet Weight
80 Oz (4 x 20 oz)
Displacement Volume
0.63L / 0.022ft3

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
2.4L / 0.0849ft3
Free Air Resonance Fs
65Hz
Mechanical Factor Qms
5.919
Electrical Factor Qes
1.121
Total Factor Qts
0.942
Moving Mass Mms
42.91g
Compliance Cms
0.103mm/N
Bl Factor Bl
4.975
Voice Coil Inductance Le
0.264 mH
Diaphragm Area Sd
128.68cm2
DC Resistance Re
2.6+2.6 ohms
Efficiency Bandwidth Product EBP
57.9

RECOMMENDED ENCLOSURES

Sealed Internal Volume
11.3L / 0.4ft3
Sealed Box Output Response
57.8Hz
Ported Internal Volume
17L / 0.6ft3
Port Size *Square (W x H x Long)
0.73" x 6.85" x 6.24" / 18.5 x 174 x 158.6mm
Port Tuning Frequency
50Hz
Ported Box Output Response
39Hz

MEASUREMENTS

Overall Diameter
6.93" / 176mm
Overall Depth
5.33" / 135.5mm
Front Mount Baffle Cutout
5.78" / 146.8mm
Mounting Depth
4.41" / 112mm
Motor Diameter
4.72" / 120mm
Gross Single Unit Weight (lb)
9.5
Dimensions W x L x H (Inches)
7.25 x 7.25 x 6.25
Quantity of Units in Master Carton
4
Gross Master Carton Weight (lb)
39
M/C Dimensions W x L x H (Inches)
15.25 x 8 x 13.5

Load More

Product Overview

DS18 ZXI6.2D

High Excursion 6.5" Car Audio Subwoofer 600W Watts 2-Ohm DVC Quad Stacked Magnets

Experience bass like never before with DS18’s ZXI6.2D: the ultimate subwoofer for enthusiasts who crave thunderous bass!
The ZXI subline is renowned for its high excursion capabilities, and the ZXI6.2D is no exception. This subwoofer handles wattage as high as 600W while delivering smooth ultra-low frequency responses. The ZXI6.2D’s lower than normal FS (Resonant Frequency), allows it to excel in larger boxes with lower tuning. Whether you prefer sealed or ported boxes, the ZXI6.2D will excel in both, giving you the flexibility to optimize placement in any vehicle.
It’s dual 2-ohm configuration and 1.5-inch voice coils, makes the ZXI6.2D a force to be reckoned with. Handling a staggering 300W RMS power and 600W of MAX power, ensuring you get the full potential out of your system. The large foam surround and non-pressed paper cone work in perfect harmony, delivering crisp, smooth bass that permeates every corner of your vehicle.
The ZXI6.2D goes beyond raw power and precision. It features a strong stamped basket adorned with show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. The quad stacked magnets on the ZXI6.2D offer a multitude of benefits, including increased magnetic field strength, improved power handling, enhanced cone control, higher excursion capabilities, greater durability, and superior heat dissipation. Not only will it impress your ears, but it will also outlast any vehicle. This subwoofer is designed to provide you with crisp and clear bass for years to come.
Immerse yourself in bass that is both thunderous and refined, thanks to DS18's commitment to quality and innovation.
