ZXI 8" High Excursion Subwoofer Quad Stacked Magnets 600 Watts Rms DVC 4-Ohm

ZXI 8" High Excursion Subwoofer Quad Stacked Magnets 600 Watts Rms DVC 4-Ohm

Name: ZXI 8" High Excursion Subwoofer Quad Stacked Magnets 600 Watts Rms DVC 4-Ohm
Brand: ZXi8.4D
SKU: ZXI8.4D
Price: 169.95 USD
Availability: InStock
Rating: 5.0 (1 reviews)

SKU: ZXI8.4D

$169.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

8" High Excursion Subwoofer
MAX Power: 1200 Watts
RMS Power: 600 Watts
Impedance: 4-Ohm 2" DVC
Quad Stacked Ferrite Magnet
86dB

In stock

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

8" DIAMETER

SUBWOOFER

4+4 OHM

VOICE COIL 2"

FERRITE MAGNET

HIGH EXCURSION SURROUND

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

SPECS

SKU
ZXI8.4D
Nominal Diameter
8" / 203.2mm
Nominal Impedance
4 + 4 ohms
RMS Power Handling
600W
Maximum Power Handling
1200W
Sensitivity (1w/1m)
86dB
Frequency Response
25-880Hz
Recommended Lo Pass Crossover
90Hz

MOTOR

Voice Coil Diameter
2" / 50.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
PPI
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Black Sandblasted
Magnet Material
Ferrite
Magnet Weight
104 Oz (4 x 26 oz)
Displacement Volume
1.02L / 0.036ft3

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
6.75L / 0.238ft3
Free Air Resonance Fs
45Hz
Mechanical Factor Qms
5.318
Electrical Factor Qes
0.791
Total Factor Qts
0.689
Moving Mass Mms
87.65g
Compliance Cms
0.135mm/N
Bl Factor Bl
8.073
Voice Coil Inductance Le
0.476 mH
Diaphragm Area Sd
188.69cm2
DC Resistance Re
4.0+4.0 ohms
Efficiency Bandwidth Product EBP
58.4

RECOMMENDED ENCLOSURES

Sealed Internal Volume
17L / 0.6ft3
Sealed Box Output Response F3
50Hz
Ported Internal Volume
28.3L / 1ft3
Port Size *Square (W x H x Long)
1.75" x 7.99" x 14.67" / 44.5 x 203 x 372.7mm
Port Tuning Frequency FB
35Hz
Ported Box Output Response F3
28Hz

MEASUREMENTS

Overall Diameter
8.58" / 218mm
Overall Depth
6.83" / 173.5mm
Front Mount Baffle Cutout
7.31" / 185.8mm
Mounting Depth
5.51" / 140mm
Motor Diameter
5.27" / 134mm
Gross Single Unit Weight
14
Dimensions W x L x H
9.5 x 9.5 x 7.75
Quantity of Units in Master Carton
2
Gross Master Carton Weight
29.5
Master Carton Dimensions W x L x H
19.5 x 10.25 x 8.5

Product Overview

DS18 ZXI8.4D

High Excursion 8" Car Audio Subwoofer 1200W Watts 4-Ohm DVC Quad Stacked Magnets

Experience bass like never before with DS18’s ZXI8.4D: the ultimate subwoofer for enthusiasts who crave thunderous bass!
The ZXI subline is renowned for its high excursion capabilities, and the ZXI8.4D is no exception. This subwoofer handles wattage as high as 1200W while delivering smooth ultra-low frequency responses. The ZXI8.4D’s lower than normal FS (Resonant Frequency), allows it to excel in larger boxes with lower tuning. Whether you prefer sealed or ported boxes, the ZXI8.4D will excel in both, giving you the flexibility to optimize placement in any vehicle.
It’s dual 4-ohm configuration and 2-inch voice coils, makes the ZXI8.4D a force to be reckoned with. Handling a staggering 600W RMS power and 1200W of MAX power, ensuring you get the full potential out of your system. The large foam surround and non-pressed paper cone work in perfect harmony, delivering crisp, smooth bass that permeates every corner of your vehicle.
The ZXI8.4D goes beyond raw power and precision. It features a strong stamped basket adorned with show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. The quad stacked magnets on the ZXI8.4D offer a multitude of benefits, including increased magnetic field strength, improved power handling, enhanced cone control, higher excursion capabilities, greater durability, and superior heat dissipation. Not only will it impress your ears, but it will also outlast any vehicle. This subwoofer is designed to provide you with crisp and clear bass for years to come.
Immerse yourself in bass that is both thunderous and refined, thanks to DS18's commitment to quality and innovation.
