SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs

SKU: SMD-8500.1D

NEW ARRIVAL

SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs
SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs

SMD Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights 8500W RMS at 1-ohm - Steve Meade Designs

SKU: SMD-8500.1D

NEW ARRIVAL

Sale price$1,499.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock

Channel: 1 Channel

Power: 8500 Watts Rms

Quantity:
  • Key Features

    • 1 Channel Subwoofer Monoblock
    • Exclusive SMD Design ~ Class D
    • 1 - 4 Ohm Stable ~ 8500 Watts @ 1 Ohm RMS
    • VM-1 Voltmeter ~ Fans ~ Linkable
    • Acrylic Window ~ Digital LED Lighting w/ Remote
    • Bass Knob ~ LED Indicators ~ Made in Korea
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    SMD-8500.1D
    RMS Power @ 4 ohm (14.4v)
    3300W
    RMS Power @ 2 ohm (14.4v)
    5700W
    RMS Power @ 1 ohm (14.4v)
    8500W

    Audio

    Frequency Response
    15Hz-250Hz
    Signal to Noise Ratio
    >98dB
    Efficiency @ 4ohm
    >86%
    Damping Factor
    300
    Input Impedance
    22K ohm
    Total Harmonic Distortion (THD)
    <0.02%
    Low Level Input Range
    200mV-6V
    High Level Input
    NO
    Selectable X-Over
    Fixed LPF
    X-Over Filter Range
    35Hz-250Hz
    Bass Boost Range
    0~9dB
    Bass Boost Frequency
    30Hz-60Hz
    Infrasonic Filter
    10Hz-30Hz
    Phase Selector
    0~180
    Operational Voltage
    8.5v-16.9v

    Features

    Amplifier Class
    Digital
    Amplifier Type
    Subwoofer
    Number of Channels
    1
    Minimum Impedance
    1 ohm
    Led Indicator
    Power / Protection / Clip
    Power Input Terminal Size
    0 AWG
    Recommended Fuse Size (Not Included)
    740A
    Cooling Fan
    Yes
    Thermal Protection
    Yes
    Over-Load Protection
    Yes
    DC Output Protection
    Yes
    Short Circuit Output Protection
    Yes
    Voltage Input Protection
    Yes
    Clipping Protection
    Yes
    Body Color / Finish
    Black
    Metal Adjustment Knobs with Click Position
    Yes
    Professional Tiffany RCA Connectors
    Yes
    Remote Level Knob with Clip indicator
    Yes (Metal Case)
    Linkable (Strap mode) Amplifier
    Yes
    Reliable Heavy Duty Korean Board Design
    Yes
    Very High Efficiency Digital Circuit Design
    Yes
    Exclusive SMD design with VM-1 Voltmeter
    Yes
    Front Acrylic Window and Digital RGB Lighting
    Yes
    IR Remote Control for LED patterns and colors
    Yes

    Measurement

    Overall Length
    23.3" / 562mm
    Overall Width
    9.15" / 232mm
    Overall Height
    3" / 76mm
    Heatsink Length
    21.6" / 550mm
    Gross Single Unit Weight
    22Lb / 9.97kg

    Load More
  • Product Overview

    Product Overview

    DS18 SMD-8500.1D

    Monoblock Amplifier with VM-1 Voltmeter and Digital LED Lights

    Introducing the SMD-8500.1D— engineered by DS18 in collaboration with Steve Meade Designs. Built for superior audio performance, it features premium Korean components and Sky High Car Audio’s OFC Internal Wiring. With DS18’s reputation as the LOUDEST in pro audio and Steve Meade’s industry-standard installation peripherals, this amp is built for extreme power and convenience.

    “When we first started working on the SMD amplifiers with DS18, I made it clear that these amplifiers needed to stand out from the rest," says Steve Meade.

    With the SMD-8500.1D, we achieved that and more. What sets the SMD-8500.1D apart is its unique clear half-top design ensuring efficient heat dissipation through a reverse-mounted board and dual cooling fans. It also features an exclusive built-in SMD VM-1 digital/analog-style LED voltmeter that monitors power draw in real-time. Customizable RGB lighting adds another layer of personalization, allowing you to match your vehicle’s interior or create dynamic light displays.

    Manufactured using premium components from Korea, this amplifier guarantees the reliability and powerful bass amplification that DS18 is known for. The SMD-8500.1D is not only visually striking but also engineered for top-tier performance. It delivers an impressive 3300W RMS at 4-ohm, 5700W RMS at 2-ohm, and 8500W RMS at 1-ohm, driving even the most demanding subwoofer setups with ease.

    The SMD-8500.1D is designed for audiophiles seeking superior bass output and power efficiency. As a Class D amplifier, it prioritizes efficiency and low heat production, delivering pristine audio performance with minimal distortion. Equipped with a precision attenuation knob for easy bass control, it maintains a <0.02% THD, ensuring exceptional Total Harmonic Distortion levels. With 0 AWG power and ground inputs and a 740A fusing requirement, it’s built for robust power delivery. Additional features include a Fixed LPF (Low-Pass Filter) and Tiffany RCA connectors for the highest quality signal transfer in your setup.

    Crafted with precision using only the best components, DS18’s SMD-8500.1D is a monoblock amplifier capable of powering high-output subwoofers with deep, controlled bass. Its advanced protection suite includes thermal overload, DC output, short circuit, and voltage input protection, ensuring safe operation in any setup.

    Push the limits of what’s possible with the SMD-8500.1D’s groundbreaking design and raw power!



FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT
