SKU: SMD-200.4AB

NEW ARRIVAL

Sale price$399.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock

Channel:

Power Rating:

Channel: 4 Channel

Power: 4 x 200 Watts Rms

Color:

Quantity:
  • Key Features

    • 4 Channel Stereo Full Range
    • Exclusive SMD Design ~ Class AB
    • 2 - 4 Ohm Stable ~ 4 X 200 Watts @ 2 Ohms RMS
    • VM-1 Voltmeter ~ Fans ~ Input Selector
    • Acrylic Window ~ Digital LED Lighting w/ Remote
    • Bass Knob ~ LED Indicators ~ Made in Korea
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    SMD-200.4AB
    RMS Power @ 4 ohm
    150W x 4
    RMS Power @ 2 ohm
    200W x 4
    RMS Power @ 1 ohm
    N/A
    RMS Power @ 4 ohm Bridge
    400W x 2

    Audio

    Operational Voltage
    8.5-16.5v
    Frequency Response
    10Hz-24KHz
    Signal to Noise Ratio
    >98dB
    Efficiency @ 4ohm
    >62%
    Damping Factor
    140
    Input Impedance
    22K ohm
    Channel Separation
    >50dB
    Total Harmonic Distortion (THD)
    0.10%
    Low Level Input Range
    200mV-6V
    High Level Input
    NO
    Selectable X-Over
    HPF/FULL/LPF
    X-Over Filter Range
    50Hz-2KHz
    Bass Boost Range
    0~9dB
    Bass Boost Frequency
    30Hz-60Hz
    Phase Selector
    0~180

    Features

    Amplifier Class
    Analog AB
    Amplifier Type
    Stereo Full-Range
    Number of Channels
    4
    Minimum Impedance
    2 Ohm Stereo / 4 Ohm Bridge
    Led Indicator
    Power / Protection / Clip
    Power Input Terminal Size
    4 AWG
    Recommended Fuse Size (Not Included)
    120A
    Cooling Fan
    Yes
    Thermal Protection
    Yes
    Over-Load Protection
    Yes
    DC Output Protection
    Yes
    Short Circuit Output Protection
    Yes
    Voltage Input Protection
    Yes
    Clipping Protection
    Yes
    Body Color / Finish
    Black
    Input Mode Selectable
    Yes (2/4ch)
    Metal Adjustment Knobs with Click Position
    Yes
    Professional Tiffany RCA Connectors
    Yes
    Remote Level Knob with Clip indicator
    Yes (Metal Case)
    Reliable Heavy Duty Korean Board Design
    Yes
    High-Power Class AB Circuit Design
    Yes
    Exclusive SMD design with VM-1 Voltmeter
    Yes
    Front Acrylic Window and Digital RGB Lighting
    Yes
    IR Remote Control for LED patterns and colors
    Yes

    Measurement

    Overall Length
    11" / 282mm
    Overall Width
    9.15" / 232mm
    Overall Height
    3" / 76mm
    Heatsink Length
    9.4" / 240mm
    Gross Single Unit Weight
    7.2Lb / 3.3Kg

    Load More
  • Product Overview

    Product Overview

    DS18 SMD-200.4AB

    4-Channel Amplifier with VM-1 Voltmeter and Digital LED Lights

    Introducing the SMD-200.4AB— engineered by DS18 in collaboration with Steve Meade Designs. Built for superior audio performance, it features premium Korean components and Sky High Car Audio’s OFC Internal Wiring. With DS18’s reputation as the LOUDEST in pro audio and Steve Meade’s industry-standard installation peripherals, this amp is built for extreme power and convenience.

    “When we first started working on the SMD amplifiers with DS18, I made it clear that these amplifiers needed to stand out from the rest." says Steve Meade.

    With the SMD-200.4AB, we achieved that and more. What sets the SMD-200.4AB apart is its unique clear half-top design, ensuring efficient heat dissipation through a reverse-mounted board and dual cooling fans. It also features an exclusive built-in SMD VM-1 digital/analog-style LED voltmeter that monitors power draw in real-time. Customizable RGB lighting adds another layer of personalization, allowing you to match your vehicle’s interior or create dynamic light displays.

    Manufactured using premium components from Korea, this amplifier guarantees the reliability and powerful sound quality that Steve Meade Designs is known for. The SMD-200.4AB is not only visually striking but also engineered for top-tier performance. It delivers an impressive 150W x 4 RMS at 4-ohm, 200W x 4 RMS at 2-ohm, and 400W x 2 RMS bridged at 4-ohm: driving even the most demanding setups with ease.

    The SMD-200.4AB is designed for audiophiles seeking superior sound quality. As a Class AB amplifier, it prioritizes clarity and detail, delivering pristine audio performance. Equipped with a precision attenuation knob for easy bass control, it maintains a .10% THD, ensuring exceptional Total Harmonic Distortion levels. With 4 AWG power and ground inputs and a 120A fusing requirement, it’s built for robust power delivery. Additional features include selectable 2/4 channel inputs and Tiffany RCA connectors for the highest quality signal transfer in your setup.

    Crafted with precision using only the best components, DS18’s SMD-200.4AB is a full-range amplifier capable of powering anything—from subs and tweeters to midbass, vocals, and any front and rear combination of speakers. Its advanced protection suite includes thermal, overload, DC output, short circuit, and voltage input protection, ensuring safe operation in any setup.

    Push the limits of what’s possible with the SMD-200.4AB’s groundbreaking design and raw power!
