IXS Shallow-Mount 12" Fiber Glass Subwoofer 800 Watts Rms SVC 4-Ohm






IXS Shallow-Mount 12" Fiber Glass Subwoofer 800 Watts Rms SVC 4-Ohm
Sale $186.96 / EACH
Reg.$219.95
15% OFF FOR MOVING SALE!
-
Key Features
- 12" Shallow Subwoofer
- MAX Power: 1600 Watts
- RMS Power: 800 Watts
- Impedance: 4-Ohm 2.5" SVC
- Ferrite Magnet
- 85dB
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
SPECS
SKU
IXS12.4S
Nominal Diameter
12" / 304.8mm
Nominal Impedance
4 ohms
RMS Power Handling
800W
Maximum Power Handling
1600W
Sensitivity (1w/1m)
85 dB
Frequency Response
20 - 600 Hz
Recommended Lo Pass Crossover
80 Hz
MOTOR
Voice Coil Diameter
2.5" / 63.5mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Paper
Dust Cap Material
Fiberglass
Surround Material
Stitched rubber
Basket Material
Aluminum
Basket Color/Finish
Corrugated Black
Magnet Material
Ferrite
Magnet Weight
62 Oz
Displacement Volume
0.93L / 0.033ft3
THIELE & SMALL PARAMETERS
Equivalent Volume Vas
42.4L / 1.49ft3
Free Air Resonance Fs
33 Hz
Mechanical Factor Qms
4.844
Electrical Factor Qes
0.996
Total Factor Qts
0.826
Moving Mass Mms
184.35 g
Compliance Cms
0.123 mm/N
Bl Factor BI
12.36
Voice Coil Inductance Le
3.989 mH
Diaphragm Area Sd
494.81 cm2
DC Resistance Re
3.9 ohms
Efficiency Bandwidth Product EBP
33.1
RECOMMENDED ENCLOSURES
Sealed Internal Volume (minimum)
28L / 1ft3
Sealed Box Output Response F3
40Hz
MEASUREMENT
Overall Diameter
12.6" / 320 mm
Overall Depth
5" / 129 mm
Front Mount Baffle Cutout
10.79" / 274 mm
Mounting Depth
4.33" / 110 mm
Motor Diameter
6.3" / 160 mm
Gross Single Unit Weight (lb)
16.5
Single Unit Box Dimensions W x L x H (Inches)
13.25 x 13.5 x 6.5
Quantity of Units in Master Carton
2
Gross Master Carton Weight (lb)
34
Master Carton Dimensions W x L x H (Inches)
14 x 14 x 14
-
Product Overview
Product Overview
DS18 IXS12.4S 12” Car Subwoofer 1600W 4-Ohm SVC Shallow Mount
Engineered with uncompromising precision and cutting-edge technology, the IXS12.4S is specifically designed to revolutionize your car audio experience.
Drawing upon the immense success of our renowned SW slim subwoofer line, the IXS series builds upon that legacy by offering even more power and depth. Available in both 10 and 12-inch variants, these subwoofers come with multiple voice coil options, allowing you to extract the maximum potential from your amplifier.
With impressive power handling capabilities rated at 800W RMS and 1600W MAX, the IXS12.4S delivers thunderous bass and dynamic performance. The IXS12.4S covers an extensive frequency range (20 – 600Hz) , capturing both the subtle nuances and the powerful impact of low-frequency sounds. It effortlessly reproduces low-frequency sounds with remarkable clarity and accuracy, ensuring that every beat is felt and heard with precision. The high sensitivity rating of 85.1dB the IXS12.4S means that it efficiently converts power into sound, requiring less power to produce impressive volume levels.
Even with its shallow mount size, this subwoofer fits snug in compact spaces, requiring less box space than other subs of its size. The versatility it offers is unmatched, providing you with endless placement options. The 4-ohm impedance of the IXS12.4S allows for seamless integration with a wide range of car audio systems. Ensuring efficient power transfer from your amplifier, maximizing the IXS12.4S’s performance and bass response.
Get ready to feel the bass like never before with the DS18 IXS12.4S—where power meets precision, and excellence becomes the new standard.
