XL 10" Mid-Bass Loudspeaker 500 Watts Rms 4-Ohm
SOLD OUT







XL 10" Mid-Bass Loudspeaker 500 Watts Rms 4-Ohm
SOLD OUT
Sale / EACH
Reg.
15% OFF FOR MOVING SALE!
-
Key Features
- 10" Mid-Bass
- MAX Power: 1000 Watts
- RMS Power: 500 Watts
- Impedance: 4 Ohm
- Ferrite Magnet
- 99.5dB
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
SPECIFICATIONS
SKU
10XL1000MB-4
Nominal Diameter
10" / 254mm
Nominal Impedance
4 ohms
RMS Power Handling
500 Watts
MAX Power Handling
1000 Watts
Sensitivity (1w/1m)
99.5dB
Frequency Response
75Hz-5KHz
Recommended HI Pass Crossover
100Hz
Sold in Pair or Single
Single
Grill Included
No
Features
Interleaved Sandwich Voice coil (ISV)
Yes
Demodulating Rings
Yes
Improved Heat Dissipation
No
Cone Shape
Exponential
Speaker Terminals
Push 8ga (4.7mm)
Motor
Voice Coil Diameter
3" / 76mm
Voice Coil Former Material
Kapton
Winding Material
CCAW (2 Layers IN/OUT)
Cone Material
Paper
Dust Cap Material
Paper
Surround Material
Cloth
Spider Diameter
5.5" / 139.7mm
Leads Type
Direct to Cone
Basket Material
Aluminum
Basket Color/Finish
Satin Black
Magnet Material
Ferrite
Magnet Weight
80 Oz
Displacement Volume
0.4L / 0.0141ft3
Thiele & Small Parameters
Voice Coil Inductance VAS
36.6L / 1.292ft3
Excursion (one way) XMAS
2mm
Free Air Resonance FS
68Hz
Mechanical Factor QMS
3.69
Electrical Factor QES
0.18
Total Factor QTS
0.172
Mechanical Mass MMS
29.64g
Mechanical Compliance CMS
0.21mm/N
BL Factor BL
14.2
Voice Coil Inductance LE
0.27mH
Cone Area SD
346.36cm2
DC Resistance RE
3.2 ohms
Mechanical Mass w/o air MMD
26g
Measurement
Overall Diameter
10.3" / 261.5mm
Overall Depth
4.73" / 120mm
Front Mount Baffle Cutout
9.2" / 233mm
Mounting Depth
4.29" / 109mm
Motor Diameter
7.48" / 190mm
-
Product Overview
Product Overview
DS18 10XL1000MB-4 10” Mid-Bass Loudspeaker 500W RMS 4-Ohm
DS18’s 10XL1000MB-4 is a high-performance speaker that sets a new standard for premium quality audio.
DS18’s 10XL1000MB-4 has an impressive nominal diameter of 10 inches, paired with a 4-ohm nominal impedance guaranteeing compatibility with a variety of car audio systems. The sensitivity of 99.5dB means that even at high volumes, your music will be distortion-free. Featuring an RMS power handling of 500W and a peak at 1000W, this speaker is built for powerful sound and crystal-clear clarity.
The heart of this beast lies in its motor, featuring a 3" voice coil optimized for thermal resistance and conductivity. One of the most remarkable features of this premium unit is its Interleaved Sandwich Voice Coil (ISV). Combined with demodulating rings, DS18’s 10XL1000MB-4 guarantees precise control and astounding durability. Its aluminum basket, finished in sleek satin black, not only adds to the aesthetic but also provides structural integrity for the powerful ferrite magnet weighing 80 Oz.
Installation is made straightforward with the 8GA push terminals engineered for secure connections, consistent performance, and a perfect fit into your vehicle.
