PRO 6.5" Slim Mid-Range Loudspeaker with Water-Resistant Cone | 200W RMS 4-Ohm
NEW ARRIVAL
PRO 6.5" Slim Mid-Range Loudspeaker with Water-Resistant Cone | 200W RMS 4-Ohm
NEW ARRIVAL
Sale / EACH
Reg.
20% OFF FOR CYBER MONDAY SALE!
-
Key Features
- 6.5” Shallow Midrange Speaker (400W MAX / 200W RMS)
- Water-Resistant Cone & Dust Cap
- 4-Ohm Impedance
- 95dB Sensitivity
- Slim 2.18” Mounting Depth
- 1.5” Kapton Voice Coil with 20oz Ferrite Magnet
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSPECS
SKU
PRO-SM6.4
Nominal Diameter
6.5” / 165.1mm
Nominal Impedance
4-Ohm
RMS Power Handling
200 Watts
MAX Power Handling
400 Watts
Sensitivity (1w/1m)
95 dB
Frequency Response
80Hz-14KHz
Recommended Hi Pass Crossover
180 Hz
MOTOR
Voice Coil Diameter
1.5” / 38.1 mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Water Resistant Paper
Dust Cap Material
Water Resistant
Surround Material
Coated Cloth
Basket Material
Steel
Basket Color
Glossy Red
Magnet Material
Ferrite
Magnet Weight
20 Oz
THIELE & SMALL PARAMETERS
Equivalent Volume
3.9L / 0.137ft3
Excursion (one way)
8 mm
Free Air Resonance
190 Hz
Mechanical Factor
9.745
Electrical Factor
1.586
Total Factor
1.321
Mechanical Mass
6.080g
Mechanical Compliance
0.134mm/N
BL Factor
3.02
Voice Coil Inductance
0.36mH
Cone Area
140.95cm2
DC Resistance
3.2 Ohms
MEASUREMENT
Overall Diameter
6.5” / 165mm
Overall Depth
2.32” / 59 mm
Front Mount Baffle Cutout
5.67“ / 144 mm
Mounting Depth
2.12” / 54 mm
Motor Diameter
4.33" / 110 mm
-
Product Overview
Product Overview
Our PRO-SM6.4 cuts through all noise in motorcycle, side-by-side, or outdoor applications! This shallow-mount 6.5” speaker can handle any ride and sound amazing doing it.
Own The Streets
Rated at 200W RMS / 400W MAX and tuned for 80Hz–14KHz, the PRO-SM6.4 balances punch and clarity insanely well. A sensitivity rating of 95dB ensures high output on any rides. Its 4-ohm single voice coil gives you flexible setup options across stock and custom installs.
Weather-Resistant Performance
The PRO-SM6.4’s water-resistant paper cone and coated dust cap ensure reliable operation when riding in harsh environments. Its coated cloth surround improves accuracy and durability over time, while the gloss red steel basket keeps it secured and stylish.
Easy Install
With a compact 2.18” mounting depth and 5.67” cutout diameter, this speaker is the ideal drop-in for riders looking to upgrade without complicated modifications.
Upgrade to the PRO-SM6.4 and experience what outdoor audio should sound like!
