EXL XX 12" High Excursion Subwoofer 2000 Watts Rms DVC 2-Ohm






EXL XX 12" High Excursion Subwoofer 2000 Watts Rms DVC 2-Ohm
Sale $382.46 / EACH
Reg.$449.95
15% OFF FOR MOVING SALE!
-
Key Features
- 12" High Excursion Subwoofer
- MAX Power: 4000 Watts
- RMS Power: 2000 Watts
- Impedance: 2-Ohm 3" DVC
- Ferrite Magnet
- 87dB
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
SPECS
SKU
EXL-XX12.2DHE
Nominal Diameter
12"
Nominal Impedance
2+2 ohms
RMS Power Handling
2000W
Maximum Power Handling
4000W
Sensitivity (1w/1m)
87dB
Frequency Response
20-1.3K Hz
Recommended Lo Pass Crossover
80 Hz
MOTOR
Voice Coil Diameter
3" / 75.6mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
Glass Fiber
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Black
Magnet Material
Ferrite
Magnet Weight
306 OZ
Displacement Volume
3.26L
THIELE & SMALL PARAMETERS
Equivalent Volume Vas
21.986L
Free Air Resonance Fs
39.8 Hz
Mechanical Factor Qms
5.128
Electrical Factor Qes
0.529
Total Factor Qts
0.468
Moving Mass Mms
302.158 g
Compliance Cms
0.025 mm/N
Bl Factor Bl
16.523
Voice Coil Inductance Le
6.9 mH
Diaphragm Area Sd
433.74 cm²
Dc Resistance Re
2 + 2 ohms
Efficiency Bandwidth Product EBP
75.2
MEASUREMENTS
Overall Diameter
12.63" / 321mm
Overall Depth
9.25" / 235mm
Front Mount Baffle Cutout
11.1" / 282mm
Mounting Depth
7.87" / 200mm
Motor Diameter
8.89" / 226mm
Gross Single Unit Weight (lb)
53.5
Dimensions W x L x H (Inches)
15 x 15 x 12.5
Quantity of Units in Master Carton
1
Gross Master Carton Weight (lb)
53.5
M/C Dimensions W x L x H (Inches)
15 x 15 x 12.5
-
Product Overview
Product Overview
DS18 EXL-XX12.2DHE 12” High Excursion Car Subwoofer 4000W MAX 2-Ohm DVC
Engineered for car audio enthusiasts, the EXL-XX12.2DHE pushes the boundaries of low-frequency bass reproduction, delivering an unparalleled audio experience that will leave you breathless.
As a high-tier addition to our acclaimed lineup, the EXL-XX12.2DHE offers an astonishing price-to-performance ratio, rivaling even the most expensive high excursion subs on the market. Crafted to meet the demands of the most discerning audiophiles, the EXL-XX12.2DHE boasts a three-inch black aluminum voice coil—a testament to its exceptional power handling capabilities and efficiency. With a remarkable power rating of 2000W RMS and a staggering MAX power of 4000W, this subwoofer packs a punch that reverberates through your entire vehicle.
The EXL-XX12.2DHE utilizes the strength of a ferrite magnet weighing in at an incredible 306 ounces. Its immense power effortlessly controls the cone movement, allowing for precise audio reproduction even at extreme volumes. The cone, crafted from high-quality paper, guarantees accurate sound reproduction, while the foam surround ensures optimal flexibility and longevity. Encased in a sleek black aluminum basket, this subwoofer exudes style and sophistication.
What sets the EXL-XX12.2DHE apart is its exceptional high excursion surround. Paired with a high resonant frequency (FS) of 39 Hz, the EXL-XX12.2DHE seamlessly delves into the subsonic range without missing a beat, provided your box is tuned accordingly. This version of the EXL-XX boasts a nominal diameter of 12" (304.8 mm) and a nominal impedance of 2+2 OHMS to amplify the performance and capabilities of this high-powered subwoofer.
The EXL-XX12.2DHE captures the essence of power, precision, and affordability, revolutionizing the way you experience bass in your vehicle.
