12" High Excursion Subwoofer with Carbon Fiber Cone | 3500W RMS / 7000W Peak | Dual 1-Ohm Voice Coil
🚨 New Arrival
🚨 New Arrival
12" High Excursion Subwoofer with Carbon Fiber Cone | 3500W RMS / 7000W Peak | Dual 1-Ohm Voice Coil
🚨 New Arrival
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
3500W RMS / 7000W MAX Power
Carbon Fiber Cone & Dust Cap
3.5" Voice Coil
22.5mm Xmax Excursion
1+1 Ohm Impedance
Improved Heat Dissipation
Hey {Recipient's Name},
{Your Name} wanted to help you out with some gift ideas ;)
Here's a super cool gift.
Cheers,
DS18
12" High Excursion Subwoofer with Carbon Fiber Cone | 3500W RMS / 7000W Peak | Dual 1-Ohm Voice Coil
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 3500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- Full-Range Class D Monoblock
- 1,500W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 2500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 3500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 5000 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 8000W RMS @ 1 Ohm – Full-Range Monoblock Power
- Compact design with Smart Cooling and LED Clipping Indicator
- Variable Low-Pass & Subsonic Filters (10Hz–2KHz & 10Hz–80Hz)
- 12dB Bass Boost @ 50Hz for maximum low-end punch
- 0GA terminals & Tiffany RCA inputs
- Tested with Audio Precision equipment for real-world durability
- Full-Range Class D Monoblock
- 12,000W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- Full-Range Class D Monoblock
- 1,500W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- Full-Range Class D Monoblock
- 1,500W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 2500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 2500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 3500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 3500 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 5000 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 1 Channel Full Range
- Class D
- 1 ~ 4 Ohm Stable
- 1 X 5000 Watts RMS @ 1 Ohm
- Clip / Protection Indicator
- Remote Level Control Knob
- 8000W RMS @ 1 Ohm – Full-Range Monoblock Power
- Compact design with Smart Cooling and LED Clipping Indicator
- Variable Low-Pass & Subsonic Filters (10Hz–2KHz & 10Hz–80Hz)
- 12dB Bass Boost @ 50Hz for maximum low-end punch
- 0GA terminals & Tiffany RCA inputs
- Tested with Audio Precision equipment for real-world durability
- 8000W RMS @ 1 Ohm – Full-Range Monoblock Power
- Compact design with Smart Cooling and LED Clipping Indicator
- Variable Low-Pass & Subsonic Filters (10Hz–2KHz & 10Hz–80Hz)
- 12dB Bass Boost @ 50Hz for maximum low-end punch
- 0GA terminals & Tiffany RCA inputs
- Tested with Audio Precision equipment for real-world durability
- Full-Range Class D Monoblock
- 12,000W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- Full-Range Class D Monoblock
- 12,000W RMS at 1 Ohm
- Compact High-Power Design
- Smart Cooling System
- Remote Level Control
- Clip, Short Circuit, and Overload Protection
- 1 Channel Subwoofer Monoblock
- Exclusive SMD Design ~ Class D
- 1 - 4 Ohm Stable ~ 3000 Watts @ 1 Ohm RMS
- VM-1 Voltmeter ~ Fans ~ Linkable
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 1 Channel Subwoofer Monoblock
- Exclusive SMD Design ~ Class D
- 1 - 4 Ohm Stable ~ 3000 Watts @ 1 Ohm RMS
- VM-1 Voltmeter ~ Fans ~ Linkable
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 4 Channel Stereo Full Range
- Exclusive SMD Design ~ Class AB
- 2 - 4 Ohm Stable ~ 4 X 200 Watts @ 2 Ohms RMS
- VM-1 Voltmeter ~ Fans ~ Input Selector
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 5 Channel Stereo Full Range & Subwoofer Monoblock
- Exclusive SMD Design ~ Class AB & D(SUB)
- 1 - 4 Ohm Stable ~ 4 x 250W at 2-Ohm Class AB + 1 x 1800W at 1-Ohm Class D
- VM-1 Voltmeter ~ Fans ~ Input Selector
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 1 Channel Subwoofer Monoblock
- Exclusive SMD Design ~ Class D
- 1 - 4 Ohm Stable ~ 2000 Watts @ 1 Ohm RMS
- VM-1 Voltmeter ~ Fans ~ Linkable
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 1 Channel Subwoofer Monoblock
- Exclusive SMD Design ~ Class D
- 1 - 4 Ohm Stable ~ 5000 Watts @ 1 Ohm RMS
- VM-1 Voltmeter ~ Fans ~ Linkable
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
Sold out
- 1 Channel Subwoofer Monoblock
- Exclusive SMD Design ~ Class D
- 1 - 4 Ohm Stable ~ 8500 Watts @ 1 Ohm RMS
- VM-1 Voltmeter ~ Fans ~ Linkable
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 4 Channel Stereo Full Range
- Exclusive SMD Design ~ Class AB
- 2 - 4 Ohm Stable ~ 4 X 300 Watts @ 2 Ohms RMS
- VM-1 Voltmeter ~ Fans ~ Input Selector
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
Sold out
- 4 Channel Stereo Full Range
- Exclusive SMD Design ~ Class AB
- 2 - 4 Ohm Stable ~ 4 X 500 Watts @ 2 Ohms RMS
- VM-1 Voltmeter ~ Fans ~ Input Selector
- Acrylic Window ~ Digital LED Lighting w/ Remote
- Bass Knob ~ LED Indicators ~ Made in Korea
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 8000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 8000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 4 Channel Stereo Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 X 300 Watts @ 4 Ohm
- Power ~ Clip ~ Protect Indicators
- Made In Korea ~ Bass Knob
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 5000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
Sold out
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 10000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 8000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 4 Channel Stereo Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 X 300 Watts @ 4 Ohm
- Power ~ Clip ~ Protect Indicators
- Made In Korea ~ Bass Knob
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 5000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
Sold out
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 10000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 10000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
Sold out
- 1 Channel Subwoofer Monoblock
- Class D
- 0.5 ~ 4 Ohm Stable
- 1 x 10000 Watts @ 1 Ohm
- Bass Knob/Voltmeter/Clip Indicator
- Made In Korea
- 0 GA OFC Ultra Flex Amplifier Wire Kit
- Up to 3000 Watts RMS
- ANL Fuse Holder with 250A
- Power & Remote Wires
- Speaker & RCA Cables
- Installation Accessories ~ RED
-
How much power can the CARBON12.1D handle?
The CARBON12.1D is rated for 3,500 watts RMS and 7,000 watts MAX. -
What impedance is the CARBON12.1D?
The CARBON12.1D uses dual 1-ohm voice coils (1+1 ohms). -
What impedance can one CARBON12.1D be wired to?
A single dual 1-ohm CARBON12.1D can be wired to 0.5 ohm in parallel or 2 ohms in series. -
What size voice coil does it use?
The CARBON12.1D uses a 3.5-inch (89 mm) aluminum voice-coil former with CCAR winding. -
What type of cone does the CARBON12.1D use?
The CARBON12.1D features a carbon-fiber cone and carbon-fiber dust cap for strength and rigidity. -
What is the Xmax of the CARBON12.1D?
The CARBON12.1D has 22.5 mm of one-way Xmax excursion. -
What frequency range does it play?
The CARBON12.1D has a rated frequency response of 10 Hz–200 Hz. -
What low-pass crossover is recommended?
DS18 recommends a 60 Hz low-pass crossover for the CARBON12.1D. -
What size sealed enclosure is recommended?
The recommended sealed internal volume is approximately 1.3 ft³ (37 L) per subwoofer. -
What size ported enclosure is recommended?
The recommended ported internal volume is approximately 2.0 ft³ (56.6 L) per subwoofer. -
What frequency should the ported enclosure be tuned to?
DS18 recommends a 35 Hz tuning frequency for the CARBON12.1D. -
What port size does DS18 recommend?
For the recommended 2.0 ft³ enclosure, DS18 specifies a rectangular port measuring approximately 2" × 12" × 20.7". -
What is the mounting depth?
The CARBON12.1D requires approximately 9.75 inches (248 mm) of mounting depth. -
What size cutout is required?
The recommended front-baffle cutout is approximately 11.15 inches (283 mm). -
What is the overall diameter of the subwoofer?
The overall diameter of the CARBON12.1D is approximately 12.8 inches (326 mm). -
What size speaker wire can the terminals accept?
The CARBON12.1D uses push terminals designed to accept up to 4-gauge speaker wire. -
What type of magnet does it use?
The CARBON12.1D uses a 425 oz ferrite magnet and an aluminum basket. -
Is the CARBON12.1D better suited for sealed or ported boxes?
The CARBON12.1D can be used in either sealed or ported enclosures. A sealed enclosure provides a more compact setup, while the DS18-recommended 2.0 ft³ ported enclosure tuned to 35 Hz provides stronger low-frequency output. -
What is the sensitivity of the CARBON12.1D?
The CARBON12.1D has a rated sensitivity of 82 dB (1W/1m). -
How many watts should my amplifier provide?
For maximum performance, choose an amplifier capable of delivering power appropriate for the CARBON12.1D's 3,500W RMS rating at your final wired impedance, while properly setting the gain to prevent clipping.
