2" Throat Bolt on Driver 360 Watts 2.5" Polyimide Vc 8-Ohm
2" Throat Bolt on Driver 360 Watts 2.5" Polyimide Vc 8-Ohm
Sale / EACH
Reg.
15% OFF FOR 4TH OF JULY SALE!
-
Key Features
- 2" Compression Driver
- RMS Power: 360 Watts(720 Watts Peak)
- Impedance: 8 Ohm ~ 118dB
- Ferrite Magnet - Polyimide Diaphragm
- Bolt On
- Easily Repaired With The D225PYVC
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSPECS
SKU
D225PY
Throat Diameter
2" / 50.8mm
Installation Type
Bolt-On
Nominal Impedance
8 Ohm
AES Power handling
180W
Program Power Handling
360W
Peak Power handling
720W
Sensitivity (1w/1m)
118dB
Frequency Response
630Hz-16KHz
Recommended Hi Pass Crossover
800Hz
Sold in Pair or Single
Single
BODY/FEATURES
Filter (Bass Blocker)
10uf/100v
Body Material
Aluminum
Body Color / Finish
Black
MOTOR
Voice Coil Diameter
2.5" / 63.5mm
Voice Coil Former Material
Kapton
Winding Material
CCA
Diaphragm Material
Polyimide
Magnet Material
Ferrite
Magnet Weight
56 Oz
MEASUREMENT
Overall Diameter
5.75" / 146mm
Overall Depth
2.82" / 71.7mm
Bolt Pattern/Type
4-M6 / 4" / 101.6mm
-
Product Overview
Product Overview
DS18 D225PY Compression Driver With 2” Bolt On Throat And 2.5” Polyimide Voice Coil
DS18’s Drivers are known for reaching EXTREME volumes without sacrificing on their efficiency and sensitivity! The D225PY takes these values to their MAX through the integration of a 2.5” Polyimide Voice Coil!
Polyimide Voice Coils allow your speakers to maintain higher levels of power without the fear of distortion and overheating. Powered by a ferrite motor, you can expect the D225PY to reach ear piercing high range frequencies.
This driver handles 180W of AES and 720W of Peak Power making this driver an amazing addition to any system that needs super loud highs with no compromises!
