CANDY Compact Full-Range Class D 4-Channel Amplifier 1600 Watts
SOLD OUT
CANDY Compact Full-Range Class D 4-Channel Amplifier 1600 Watts
SOLD OUT
Sale / EACH
Reg.
20% OFF FOR CYBER MONDAY SALE!
Channel:
Power Rating:
Channel: 4 Channel
Power: 4 x 120 Watts Rms
Color:
Discontinued Product
This product is discontinued. Check out these alternatives:
Or
We will notify you when it arrives:
-
Key Features
- 4 Channel Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 x 120 Watts @ 4 Ohm
- Compact Design
- Built in Crossover
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSPECS
SKU
CANDY-X4B
Total Watts (Peak)
1600W
RMS Power @ 4 Ohm
120W x 4
RMS Power @ 2 Ohm
200W x 4
RMS Power @ 4 Ohm Bridge
350W x 2
Audio
Frequency Response
20Hz-20Khz
Signal to Noise Ratio
>70 dB
Efficiency @ 4ohm
>75%
Damping Factor
26
Input Impedance
10K ohm
Channel Separation
50 dB
Total Harmonic Distortion (THD)
0.5%
Low Level Input Range
0.2-6V
High Level Input
Yes
Selectable X-Over
LPF/FULL/HPF
X-Over Filter Range
40Hz-2kHz
Bass Boost Range
0dB~12dB
Bass Boost Frequency
Fixed 50Hz
Features
Amplifier Class
Digital
Amplifier Type
Stereo Full Range
Number of Channels
4
Minimum Impedance
2 ohm
Led Indicator
Power / Protection
Power Input Terminal Size
4Ga
Fuse Size
25A x 2
Remote Level Control
No
Cooling Fan
No
Thermal Protection
Yes (>158F)
Over-Load Protection
Yes
DC Output Protection
No
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (9-16v)
Clipping Protection
No
Body Color / Finish
Black Matte
Measurement
Overall Length
8.3" / 211mm
Overall Width
5.9" / 150mm
Overall Height
2.16" / 47.5mm
Heatsink Length
7" / 228mm
Gross Single Unit Weight
3
-
Product Overview
Product Overview
DS18 CANDY-X4B 4-Channel Digital Amplifier
Give your system some flavor with the CANDY-X4B! Designed for power and precision, this high-performance car amplifier is perfect for any demanding system.
With a peak power of 1600W and RMS power ratings of 4 x 120W at 4 ohm, 4 x 200W at 2 ohm, and 2 x 350W at 4 ohm bridge: you can trust the CANDY-X4B to push your audio system past its full potential.
Built with advanced features like high-level input terminals and auto turn-on/off functionality, this digital amplifier ensures seamless integration with any car audio setup. The versatile crossover options (LPF/FULL/HPF) and adjustable frequency range (40Hz to 2kHz) offer you complete control over your sound. Plus, the bass boost feature, adjustable from 0dB to +12dB, ensures that every beat is hard and sweet!
Compact in size yet robust in performance, DS18’s CANDY-X4B is easy to install and fits perfect into any vehicle. User safety and product reliability are paramount with the CANDY-X4B. It’s protection features include thermal, overload, and short circuit output protection.
Crank up the flavor with the CANDY-X4B - upgrade now for power that never fades!
