IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm

SKU: IXS10.2D
IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm
IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm
IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm
IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm
IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm

IXS Shallow-Mount 10" Fiber Glass Subwoofer 600 Watts Rms DVC 2-Ohm

SKU: IXS10.2D
$239.95
/EACH
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
In stock

Size: 10"

10"
12"

Impedance: Dual Voice Coil 2-Ohm

Dual Voice Coil 2-Ohm
Dual Voice Coil 4-Ohm
Single Voice Coil 4-Ohm
Quantity:

  • Key Features

    • 10" Shallow Subwoofer
    • MAX Power: 1200 Watts
    • RMS Power: 600 Watts
    • Impedance: 2-Ohm 2.5" DVC
    • Ferrite Magnet
    • 84dB

  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    IXS10.2D
    Nominal Diameter
    10" / 254mm
    Nominal Impedance
    2+2 ohms
    RMS Power Handling
    600w
    Maximum Power Handling
    1200w
    Sensitivity (1w/1m)
    84 dB
    Frequency Response
    20 - 800 Hz
    Recommended Lo Pass Crossover
    90 Hz

    MOTOR

    Voice Coil Diameter
    2.5" / 63.5mm
    Voice Coil Former Material
    Aluminum
    Winding Material
    Copper
    Cone Material
    Paper
    Dust Cap Material
    Fiberglass
    Surround Material
    Stitched rubber
    Basket Material
    Aluminum
    Basket Color/Finish
    Corrugated Black
    Magnet Material
    Ferrite
    Magnet Weight
    62 Oz
    Displacement Volume
    0.9L / 0.032ft3

    THIELE & SMALL PARAMETERS

    Equivalent Volume Vas
    13.95L / 0.49ft3
    Free Air Resonance Fs
    38 Hz
    Mechanical Factor Qms
    5.88
    Electrical Factor Qes
    0.87
    Total Factor Qts
    0.76
    Moving Mass Mms
    200 g
    Compliance Cms
    88.46 mm/N
    Bl Factor BI
    13.97
    Voice Coil Inductance Le
    4.58 mH
    Diaphragm Area Sd
    333.29 cm2
    DC Resistance Re
    1.8+1.8 ohms
    Efficiency Bandwidth Product EBP
    43.6

    RECOMMENDED ENCLOSURES

    Sealed Internal Volume (minimum)
    14.2L / 0.5ft3
    Sealed Box Output Response F3
    44Hz

    MEASUREMENT

    Overall Diameter
    10.63" / 270 mm
    Overall Depth
    4.48" / 114 mm
    Front Mount Baffle Cutout
    9.25" / 235 mm
    Mounting Depth
    3.66" / 93 mm
    Motor Diameter
    6" / 154 mm
    Gross Single Unit Weight (lb)
    15
    Single Unit Box Dimensions W x L x H (Inches)
    11.25 x 11.25 x 5.75
    Quantity of Units in Master Carton
    2
    Gross Master Carton Weight (lb)
    31
    Master Carton Dimensions W x L x H (Inches)
    12 x 12 x 12.5

    Load More

  • Product Overview

    Product Overview

    DS18 IXS10.2D

    10” Car Subwoofer 1200W 2-Ohm DVC Shallow Mount

    Engineered with uncompromising precision and cutting-edge technology, the IXS10.2D is specifically designed to revolutionize your car audio experience.
    Drawing upon the immense success of our renowned SW slim subwoofer line, the IXS series builds upon that legacy by offering even more power and depth. Available in both 10 and 12-inch variants, these subwoofers come with multiple voice coil options, allowing you to extract the maximum potential from your amplifier.
    With impressive power handling capabilities rated at 600W RMS and 1200W MAX, the IXS10.2D delivers thunderous bass and dynamic performance. The IXS10.2D covers an extensive frequency range (20 – 800Hz) , capturing both the subtle nuances and the powerful impact of low-frequency sounds. It effortlessly reproduces low-frequency sounds with remarkable clarity and accuracy, ensuring that every beat is felt and heard with precision. The high sensitivity rating of 84dB the IXS10.2D means that it efficiently converts power into sound, requiring less power to produce impressive volume levels.
    The dual voice coil configuration on the IXS10.2D offer increased wiring options, greater amplifier compatibility, higher power handling, improved sound quality, flexibility in subwoofer configuration, and enhanced bass output. Even with its shallow mount size, this subwoofer fits snug in compact spaces, requiring less box space than other subs of its size. The versatility it offers is unmatched, providing you with endless placement options. The 2+2-ohm impedance of the IXS10.4D allows for seamless integration with a wide range of car audio systems. Ensuring efficient power transfer from your amplifier, maximizing the IXS10.2D’s performance and bass response.
    Get ready to feel the bass like never before with the DS18 IXS10.2D—where power meets precision, and excellence becomes the new standard.
