ZXI 6.5" 2-Way Coaxial Speakers with Kevlar Cone 80 Watts Rms 4-Ohm

Name: ZXI 6.5" 2-Way Coaxial Speakers with Kevlar Cone 80 Watts Rms 4-Ohm
Brand: ZXI-654
SKU: ZXI-654
Price: 94.95 USD
Availability: InStock
Rating: 4.92 (13 reviews)

SKU: ZXI-654

ZXI 6.5" 2-Way Coaxial Speakers with Kevlar Cone 80 Watts Rms 4-Ohm

SKU: ZXI-654

$94.95

/PAIR

Ships Free Next Business Day From Miami, FL, USA

In stock

Size: 6.5"

6.5"

Quantity:

Key Features
- 6.5" 2-Way Coaxial
- MAX Power: 240 Watts
- RMS Power: 80 Watts
- Impedance: 4 Ohm
- Barium Ferrite & Neodymium Magnets
- Pair ~ 87dB
Technical Data - Manual

DOWNLOAD THE USER MANUAL

SPECS

SKU
ZXI-654
Nominal Diameter
6.5 Inches
Nominal Impedance
4 ohm
RMS Power Handing
80 WATTS
MAX Power Handing
240 WATTS
Sensitivity
89 dB
Frequency Response
40 Hz - 20 KHz
Recommended HI Pass
60 Hz
Speaker Type
2-Way

MIDRANGE

Voice Coil Diameter
25.5 mm (1 inch)
Voice Coil Former Material
KSV
Winding Material
EISV
Cone Material
Glass fiber
Surround Material
Rubber
Basket Material
Steel
Magnet Material
Barium Ferrite
Magnet Weight
14.46 oz / 410 g

TWEETER

Nominal Diameter
25.4 mm (1 inch)
Voice Coil Diameter
20.4 mm (0.8 inch)
Voice Coil Former Material
KSV
Winding Material
EISVM
Diaphragm Material
PEI
Magnet Material
Neodymium
Magnet Weight
8.5 g / 0.3 oz

THIELE & SMALL PARAMETERS

Vas
10.84 LTR
Xmax
2.7 mm
Fs
64 Hz
Qms
9.44
Qes
0.79
Qts
0.73
Mms
13.72 g
Cms
444 mm / N
BL
5.1
Le
228 mH
Sd
131 cm2
Re
3.5 ohm
Mmd
12 g

MEASUREMENTS

Overall Diameter
6.50 inch (165 mm)
Overall Depth
72 mm (2.83 inch)
Front Mount Baffle Cutout
141 mm (5.55 inch)
Mounting Depth
60 mm (2.36 inch)
Motor Diameter
94 mm (3.70 inch)
Product Weight
5.5 lbs
Product Dimensions
15.75 x 7.75 x 3.75
M/C Weight
35 lbs
M/C Dimensions
16.5 x 16.75 x 12.25
M/C QTY
6
Sold In
Pair

Load More Show Less
Product Overview

Product Overview

DS18 ZXI-654

Kevlar 6.5" 2-Way Coaxial Car Speaker 240 Watts 4-Ohm

Experience music like never before with the DS18 ZXI-654 - the perfect solution for audiophiles looking to elevate their car audio system’s sound quality. This speaker is designed to deliver powerful sound with little to no distortion, ensuring an enhanced listening experience that will leave you wanting more.

The ZXI-654 features a Kevlar cone woofer with a rubber surround, the perfect combination for delivering precise and punchy bass responses. Kevlar is a durable and lightweight material that is commonly used in bulletproof vests: but is ideal for creating speaker cones due to its excellent strength-to-weight ratio. Combined with the rubber surround the ZXI-654 comes with reduces unwanted vibrations, resulting in a cleaner and more accurate sound.

The 2-way design on the ZXI-654 equips the 6.5” woofer with a 1” Neodymium Magnet Tweeter, which delivers unmatched clarity and detail in the higher end of the frequency range. Neodymium magnets are known for their lightweight and powerful properties, allowing the speaker to reproduce accurate high frequencies without increasing the overall weight of the speaker resulting in a more balanced and natural sound.

With frequency responses ranging from 40Hz – 20KHz, the ZXI-654 is built to deliver clear and powerful sound across the entire frequency spectrum.

No matter where your car takes you, DS18’s ZXI-654 will immerse you in the music like never before. Upgrade with DS18’s ZXI-654 and experience the difference today.
