ZR 1-Channel Class D Amplifier 500 Watts Rms @ 1-Ohm

ZR 1-Channel Class D Amplifier 500 Watts Rms @ 1-Ohm

Name: ZR 1-Channel Class D Amplifier 500 Watts Rms @ 1-Ohm
Brand: ZR500.1D
SKU: ZR500.1D
Price: 169.95 USD
Availability: InStock
Rating: 5.0 (1 reviews)

SKU: ZR500.1D

$169.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

1 Channel Subwoofer Monoblock
Class D
1 ~ 4 Ohm Stable
1 x 500 Watts @ 1 Ohm
Clip/Protection Indicator
Bass Control Knob

In stock

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

1 CHANNEL

MONOBLOCK SUBWOOFER

CLASS D

LED INDICATOR

REMOTE LEVEL CONTROL

LPF Fixed

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

SPECS

SKU
ZR500.1D
Total Watts (Peak)
1500W
RMS Power @ 4 Ohm
200W
RMS Power @ 2 Ohm
300W
RMS Power @ 1 Ohm
500W

AUDIO

Frequency Response
10-220Hz
Signal to Noise Ratio
>95dB
Efficiency @ 4 Ohm
85%
Damping Factor
160
Input Impedance
20K ohm
Channel Separation
N/A
Total Harmonic Distortion (THD)
0.01%
Low Level Input Range
0.2-6V
High Level Input
No
Selectable X-Over
LPF Fixed
X-Over Filter Range
50-220Hz
Bass Boost Range
0/6/12dB
Bass Boost Frequency
45Hz
Infrasonic Filter
10-50Hz
Phase Selector
No

FEATURES

Amplifier Class
Digital
Amplifier Type
Monoblock Subwoofer
Number of Channels
1
Minimum Impedance
1 Ohm
Led Indicator
Clipping/protect/power
Power Input Terminal Size
4 GA
Fuse Size
60 A
Remote Level Control
Yes / Dash Mount
Cooling Fan
No
Voltmeter
No
Thermal Protection
Yes
Over-Load Protection
Yes
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes <9 / >16 Volts
Clipping Protection
Yes
Body Color / Finish
Black Aluminum Brush

MEASUREMENT

Overall Length
8.46" / 215mm
Overall Wide
7.24" / 184mm
Overall Height
2" / 53mm
Heatsink Length
7" / 180mm
Gross Single Unit Weight
3.15Lb

Product Overview

DS18 ZR500.1D

ZR Class D 1-Channel Monoblock Car Amplifier 500W RMS

The ZR series is a game-changer, crafted to optimize your sound system and unleash its true potential!
With DS18's ZR500.1D, the possibilities are endless. It boasts an impressive array of tuning options, including Lowpass, Subsonic, as well as a Gain Knob and Bass Boost Switch Selector that allows you to fine-tune every song to your desired frequency. This level of customization ensures that each note is reproduced with impeccable precision and tailored to your unique listening preferences.
Delivering a commendable 200W RMS @ 4-Ohm, 300W RMS @ 2-Ohm, and 500W RMS @ 1-Ohm, the ZR500.1D provides the perfect amount of power to fuel your bass. It effortlessly propels your speakers to their maximum potential, creating a rich and immersive audio environment.
The ZR500.1D is a testament to DS18's commitment to excellence. Its Full Range design ensures maximum efficiency, while the impressive 2400 Peak Wattage makes sure all your speakers get the juice they deserve. With a frequency response of 10Hz – 220Hz, this amplifier faithfully reproduces the deepest lows with remarkable clarity and accuracy.
The ZR500.1D is designed to optimize your sound system for powerful performance during every session. The LED indicators for Clipping, Power, and Protect provide valuable visual feedback that ensure optimal performance. The power and ground terminals are designed to accommodate 4 Ga wires, ensuring a secure and reliable connection. Additionally, the selectable X-Over options grant you the ability to fine-tune your bass, allowing for seamless integration with your existing sound system and putting you in complete control of your soundstage.
Experience the DS18 difference today with the ZR500.1D and discover a new dimension of car audio excellence.
