ZR 10" Subwoofer 700 Watts Rms DVC  2-Ohm
DS18 ELITE-Z 10" Subwoofer with 1400 Watts DVC 2-Ohms audio subwoofers
DS18 ELITE-Z 10" Subwoofer with 1400 Watts DVC 2-Ohms audio subwoofers

ZR 10" Subwoofer 700 Watts Rms DVC 2-Ohm

SKU: ZR10.2D

Sale price$149.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 10" Subwoofer
  • MAX Power: 1400 Watts
  • RMS Power: 700 Watts
  • Impedance: 2-Ohm 2.5" DVC
  • Ferrite Magnet
  • 81dB

In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

10

10" DIAMETER

SUBWOOFER

SUBWOOFER

2+2 OHM

2+2 OHM

VOICE COIL 2.5

VOICE COIL 2.5"

FERRITE MAGNET

FERRITE MAGNET

NON-PRESSED PAPER CONE

NON-PRESSED PAPER CONE

DOWNLOAD THE USER MANUAL

SPECS

SKU
ZR10.2D
Nominal Diameter
10" / 254mm
Nominal Impedance
2 + 2 Ohm
RMS Power Handling
700W
Maximum Power Handling
1400W
Sensitivity (1w/1m)
81 dB
Frequency Response
27-200Hz
Recommended Lo Pass Crossover
100Hz

MOTOR

Voice Coil Diameter
2.5" / 61.6mm
Voice Coil Former Material
Aluminum
Winding Material
Copper
Cone Material
Non-Pressed Paper
Dust Cap Material
PPI
Surround Material
Foam
Basket Material
Steel
Basket Color/Finish
Black Matte
Magnet Material
Ferrite
Magnet Weight
100 Oz
Displacement Volume
0.05 ft3

THIELE & SMALL PARAMETERS

Equivalent Volume Vas
8.26 L
Free Air Resonance Fs
34 Hz
Mechanical Factor Qms
4.3
Electrical Factor Qes
0.8
Total Factor Qts
0.67
Moving Mass Mms
252g
Compliance Cms
53.37? m/N
Bl Factor BI
8.78
Voice Coil Inductance Le
546.4m mH
Diaphragm Area Sd
333.29 Cm2
DC Resistance Re
1.8 + 1.8 Ohm
Efficiency Bandwidth Product EBP
42.5

MEASUREMENTS

Overall Diameter
10.31" / 262mm
Overall Depth
6.92" / 176mm
Front Mount Baffle Cutout
9" / 229mm
Mounting Depth
6" / 152.3mm
Motor Diameter
6.1" / 155mm
Gross Single Unit Weight (lb)
17.5
Dimensions W x L x H (Inches)
11.5 x 11.5 x 8.25
Quantity of Units in Master Carton
2
Gross Master Carton Weight (lb)
36
M/C Dimensions W x L x H (Inches)
12.25 x 12.25 x 17.75

Load More

Product Overview

DS18 ZR10.2D

10” Car Subwoofer 1400W 2-Ohm DVC

Introducing the DS18 ZR10.2D, a true powerhouse designed to deliver mind-blowing bass and precision performance.
The ZR subline is renowned for its exceptional performance, and the ZR10.2D is no exception. With a robust 1400W of MAX power handling and 700W of RMS power handling, the ZR10.2D guarantees a spine-tingling audio experience that will leave you craving for more. Its 2.5-inch high-strength aluminum voice coil ensures that every note is delivered with precision and clarity, elevating your car audio system to new heights. Its 2+2 ohm dual voice coil configuration allows you to match your amplifier's optimal impedance, providing maximum power transfer and efficiency.
With DS18’s ZR10.2D, you don't just get exceptional performance; you also get unmatched style and unbreakable durability. The ZR10.2D features a strong stamped basket that not only provides structural integrity but also showcases show-quality DS18 logos on the frame, magnet boot, magnet, and dust cap. Its matte black finish adds a touch of elegance, making it a visually stunning addition to any car audio setup.
With a frequency response ranging from 27Hz to 200Hz and a sensitivity of 81 dB, the ZR10.2D captures every nuance of your music, delivering it with crystal-clear precision. The recommended low-pass crossover of 100Hz ensures seamless integration with your existing audio system, allowing your music to shine in all its glory.
With its striking design, exceptional performance, and versatility, the ZR10.2D is the perfect choice for car audio enthusiasts who demand nothing but the best.
