6-Way Active Crossover with Remote Gain Control

SKU: XM6LD

SOLD OUT

6-Way Active Crossover with Remote Gain Control
6-Way Active Crossover with Remote Gain Control
6-Way Active Crossover with Remote Gain Control
6-Way Active Crossover with Remote Gain Control

6-Way Active Crossover with Remote Gain Control

SKU: XM6LD

SOLD OUT

Sale price$263.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • Key Features

    • Active Crossover
    • 6-Way
    • Front/Rear/Sub Inputs
    • High/Band Pass 1,2,3/Mid-Bass/Sub Outputs
    • On/Off Button for each Channel
    • Bass Control Knob
  • Technical Data - Manual

    Specifications

    SKU
    XM6LD
    Total Harmonic Distortion @ 1kHz
    0.04%
    Signal to Noise Ratio
    >105dB
    Stereo Separation
    >70dB
    Current Drain
    200mA
    Remote Turn-on Time
    0.5 Sec
    Recommended Fuse
    1A

    Input Impedance / Voltage

    Front & Rear & Subwoofer
    22K-Ohms
    Input Voltage
    150mV~6V
    Crossover Cut Off Slope
    12dB/Octave
    Maximum Output Voltage
    11.5V

    Subwoofer

    Low Pass Crossover Frequency
    40~90Hz
    Subsonic Filter
    10Hz~30Hz
    Phase Shift
    0 to 180 degrees
    Bass Level Remote Control
    Wired

    Rear (Mid Bass/Band Bass 3)

    Mid Bass: Low Pass Crossover Frequency
    40Hz ~1KHz
    High Pass Crossover Frequency
    40Hz ~1kHz
    Low Pass Crossover Frequency
    1KHz~12KHz

    Front (HIGH/Band Pass1/Band Pass2)

    High Pass Crossover Frequency
    1KHz~12KHz
    High Pass Crossover Frequency
    40Hz ~1KHz
    Low Pass Crossover Frequency
    1KHz~12KHz

    Weight and Dimensions

    Gross Single Unit Weight (lb)
    3.5
    Box Dimensions L x W x H (Inches)
    14.25 x 8.5 x 2.25
    Quantity of Units in M/C
    10
    Gross M/C Weight (lb)
    37.5
    M/C Dimensions L x W x H (Inches)
    23 x 15 x 9.5

    Load More
  • Product Overview

    Product Overview

    DS18 XM6LD

    6-Way Active Crossover with Remote Gain Control

    DS18’s XM6LD is crafted for flawless frequency distribution throughout your system, ensuring unparalleled clarity and peak efficiency for your acoustic needs. This 6-Way Active Crossover serves as the heart of your system, optimizing every aspect of your audio. With its impressive 6 separate bands and line driver options, the XM6LD allows you to elevate your input voltage, achieving a perfect match with your amplifier voltage.
    DS18 understands the importance of precise tuning in achieving audio excellence. That's why the XM6LD comes equipped with easy-to-use tuning controls that provide unparalleled accuracy. High pass and band pass filters allow you to effortlessly target your desired midrange and high-range frequencies, ensuring your sound reproduction is exact and tailored to your preferences.
    The XM6LD's master gain knob, coupled with its six level adjustment knobs, empowers you to increase voltage via the line driver, ensuring your amplifiers receive the optimal signal voltage they crave for maximum volume. Drawing a mere 200mA of current and with a remote turn-on time of just 0.5 seconds, the XM6LD combines efficiency with speed, ensuring seamless integration into your audio setup. With an input impedance of 22K-Ohms and an input voltage range of 150mV to 6V, it accommodates a wide array of audio sources, enabling you to unleash the full potential of your music.
    As an esteemed member of the DS18 family, the XM6LD is meticulously designed to meet the exacting standards of car audio enthusiasts. Its dimensions of 1.5" in height, 6.5" in length, and 8.5" in width make it compact and easily installable, blending seamlessly into your system.

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
K
Kyle Ramirez
Excellent Crossover for Crisp, Clear Sound

This crossover exceeded my expectations. It delivers crisp, balanced sound and allows for fine-tuning between frequencies. Easy to install and adjust, it's a fantastic upgrade for any sound system. Highly recommend!

P
Pablo Rodrigues

Great product separates everything nice
