DS18 PRO-ZXI694BM 6X9" Mid-Range Loudspeaker with Bullet 600 Watts 4-Ohms
DS18 PRO-ZXI694BM 6X9" Mid-Range Loudspeaker with Bullet 600 Watts 4-Ohms
DS18 PRO-ZXI694BM 6X9" Mid-Range Loudspeaker with Bullet 600 Watts 4-Ohms
PRO-ZXI 6x9" Mid-Range Bullet Loudspeaker Neodymium/Ferrite Magnets 300 Watts Rms 4-Ohm
DS18 PRO-ZXI694BM 6X9" Mid-Range Loudspeaker with Bullet 600 Watts 4-Ohms
DS18 PRO-ZXI694BM 6X9" Mid-Range Loudspeaker with Bullet 600 Watts 4-Ohms

PRO-ZXI 6x9" Mid-Range Bullet Loudspeaker Neodymium/Ferrite Magnets 300 Watts Rms 4-Ohm

SKU: PRO-ZXI694BM

Sale price$82.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 6X9" Mid-Range w/Bullet
  • MAX Power: 600 Watts
  • RMS Power: 300 Watts
  • Impedance: 4-Ohm
  • Ferrite & Neodymium Magnet
  • 98dB
In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

6X9

6X9" DIAMETER

MID-RANGE

MID-RANGE

4 OHM

4 OHM

PAPER CONE

PAPER CONE

ALUMINUM BASKET

ALUMINUM BASKET

FERRITE + NEODYMIUM MAGNET

FERRITE + NEODYMIUM MAGNET

DOWNLOAD THE USER MANUAL

SPECS

SKU
PRO-ZXI694BM
Nominal Diameter
6x9" / 152.4 x 228.6mm
Nominal Impedance
4 OHMS
RMS Power Handing
300 Watts
Maximum Power Handing
600 Watts
Sensitivity (1w/1m)
98dB
Frequency Response
80Hz - 12.5KHz
Recommended Hi Pass Crossover
100 Hz

SPECS

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Glass Fiber
Winding Material
CCAW
Basket Material
Aluminum
Magnet Weight
30 + 3 Oz

THIELE & SMALL PARAMETERS

Vas
14.9L / 0.5271f
Xmax
7.2mm
Fs
100Hz
Qms
10.64
Qes
0.439
Qts
0.421
Re
3.6 ohms

MEASUREMENTS

Overall Diameter
9.43x6.57" / 240x167mm
Front Mount Baffle Cutout
8.74x6" / 222x153mm
Mounting Depth
3.38" / 86mm
Overall Depth
3.7" / 94mm
Product Weight
6 lbs
Product Dimensions
10.25 x 7.25 x 4.25
M/C Weight
49 lbs
M/C Dimensions
21 x 15.25 x 9.5
M/C QTY
8
Sold In
Piece

Load More

Product Overview

DS18 PRO-ZXI694BM

6x9” Mid-Range Loudspeaker with Bullet 600W 4-Ohm



Introducing the DS18 PRO-ZXI694BM - the ultimate audio solution for the music lover who demands nothing but the best! With its sleek black basket face and bullet dust cap, this speaker not only looks great but also sounds phenomenal, delivering clear, crisp, and powerful mid and high range frequencies with ease.
Designed with the audio enthusiast in mind, the ZXI series takes Pro Audio to new heights of elegance, clarity, and loudness. The PRO-ZXI694BM is perfect for anyone who wants unparalleled volume and sound quality without sacrificing efficiency or performance.
The bullet design of the DS18 PRO-ZXI694BM helps enhance its frequency response, which ranges between 80Hz and 12.5KHz, and improves its ability to handle mid-range frequencies. The bullet shape of the dust cap allows for smoother and more efficient sound dispersion, which helps to minimize distortion and improve clarity, even at higher volumes.
With a sensitivity rating of 98dB, this speaker is highly efficient and requires less power to achieve the same volume as less sensitive speakers. This translates to a cleaner and clearer sound with less distortion, even at high volumes.
The PRO-ZXI694BM's magnet weighs in at a light 30 Oz + 3 Oz, constructed from high-quality ferrite, ensuring that it can handle the power thrown at it efficiently. Its 3.38" mounting depth makes installation a breeze, allowing you to easily upgrade your car's audio system without breaking a sweat.
The PRO-ZXI694BM is the perfect addition to any audio system, offering a premium listening experience that is unmatched by other speakers on the market.
