PRO 6x9" Neodymium Carbon Fiber Water resistant Cone Mid-Bass Loudspeaker 300 Watts Rms 4-Ohm
PRO 6x9" Neodymium Carbon Fiber Water resistant Cone Mid-Bass Loudspeaker 300 Watts Rms 4-Ohm
Sale / EACH
Reg.
15% OFF FOR MOVING SALE!
-
Key Features
- 6X9" Mid-Bass
- Water Resistant Carbon Fiber Cone
- RMS Power: 300 Watts(600 Watts Peak)
- Impedance: 4 Ohm
- Neodymium Magnet
- 95dB
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSPECS
SKU
PRO-CF69.4NR
Nominal Diameter
6x9" / 152 x 228mm
Nominal Impedance
4 OHMS
RMS Power Handling
300 WATTS
Maximum Power Handling
600 WATTS
Sensitivity (1w/1m)
95 dB
Frequency Response
63Hz - 12KHz
Recommended Hi Pass Crossover
80 Hz
SPECS
Voice Coil Diameter
2" / 50 mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
10.5Oz / 0.3Kg
THIELE & SMALL PARAMETERS
Vas
12.75L / 0.45 ft3
Xmax
2.5 mm
Fs
83 Hz
Qms
12.16
Qes
0.69
Qts
0.65
Re
3.4 OHM
MEASUREMENTS
Overall Diameter
6.48" x 9.29" / 164.5 x 236 mm
Front Mount Baffle Cutout
5.94" x 8.58" / 151 x 218 mm
Mounting Depth
3.25" / 82.5 mm
Overall Depth
3.44" / 87.5 mm
Product Weight
4.5 lbs
Product Dimensions
10.75 x 8 x 4.5
M/C Weight
18.5 lbs
M/C Dimensions
16.5 x 11.25 x 10.5
M/C QTY
4
Sold In
Piece
-
Product Overview
Product Overview
DS18 PRO-CF69.4NR 6x9” Mid-Bass Loudspeaker with Water Resistant Carbon Fiber Cone and Neodymium Rings Magnet 600W 4-Ohm
DS18 proudly presents a game-changer in the world of car audio: the PRO-CF69.4NR. This speaker combines cutting-edge technology with unparalleled craftsmanship to deliver an audio experience that will leave you breathless.
At the heart of the PRO-CF69.4NR lies a Neodymium magnet, the gold standard in car audio magnet technology. Renowned for its exceptional strength and efficiency, the Neodymium magnet propels sound waves with unrivaled power and precision.
But that's not all! DS18 understands the needs of car audio enthusiasts like you. That's why the PRO-CF69.4NR is not only water-resistant but specifically designed to thrive in the face of the elements. Its high-tech carbon fiber cone not only delivers exceptional sound quality but also adds a touch of elegance to your audio setup. Encased by a super-strong rubber surround, this speaker is built to withstand the test of time, ensuring countless hours of audio pleasure without compromise. Rain or shine, this speaker will continue to perform at its peak, allowing you to enjoy your music wherever your adventurous spirit takes you.
With a rating of 300 watts RMS and a maximum power handling of 600 watts, this speaker thrives on pushing boundaries. Immerse yourself in crystal-clear sound, deep bass, and heart-pounding beats, all with the confidence that your speaker can handle whatever you throw its way.
With its water-resistant construction, Neodymium magnet, high-tech carbon fiber cone, and super-strong rubber surround, the PRO-CF69.4NR offers exceptional performance, unmatched versatility, and a visually stunning presence.
