NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black
NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black

NXL 10" 2-Way Coaxial Marine Speaker With LED RGB Lights 200 Watts Rms 4-Ohm -Black

SKU: NXL-10M/BK

Sale price$369.95
/PAIR
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 10" 2-Way Marine Speaker
  • RMS Power: 200 Watts
  • Impedance: 4 Ohm
  • Ferrite & Neodymium Magnets
  • RGB LED Lights
  • Water Resistant IP65
In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT
FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

10

10" DIAMETER

2-WAY COAXIAL

2-WAY COAXIAL

4 OHM

4 OHM

IP65 WATERPROOF RATING

IP65 WATERPROOF RATING

BUILT IN TWEETER

BUILT IN TWEETER

RGB LED LIGHTS

RGB LED LIGHTS

DOWNLOAD THE USER MANUAL

SPECS

SKU
NXL-10M/BK
Nominal Diameter
10" / 254mm
Nominal Impedance
4 Ohm
RMS Power Handling
200W
MAX Power Handling
600W
Sensitivity (1w/1m)
94.3dB
Frequency Response
35Hz-20Khz
Recommended HI Pass Crossover
50Hz

Body / Features

UV Compliant
Yes, 100% Stable
Marine Grade Type
IP65
RGB LED
Yes, RGB integrated
Grill Type
Injection Molded Composite ASA with 316 Stainless Steel mesh
Pair
Yes
Color / Finish
Black / Satin

Woofer Specifications

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Injection Molded Polypropylene + UV Compliant
Surround Material
Butyl (Rubber)
Basket Material
High Temp Injection Molded Composite ASA with UV Protection coating
Magnet Material
Ferrite (Y35) + Neodymium (N35)
Magnet Weight
50oz + 0.56oz

Tweeter Specifications

Nominal Diameter
1" / 25.4mm
Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
PEN
Magnet Material
Neodymium (N38H)
Magnet Weight
0.51oz

Thiele & Small Parameters

Equivalent Volume Vas
197.13L / 6.96ft3
Excursion (one way) Xmax
6mm
Free Air Resonance Fs
42Hz
Mechanical Factor Qms
6.874
Electrical Factor Qes
0.838
Total Factor Qts
0.747
Moving Mass Mms
11.37g
Compliance Cms
1.264mm/N
Bl Factor Bl
3.4
Voice Coil Inductance Le
0.60712mH
Cone Area Sd
333.29 cm2
DC Resistance Re
3.2ohms
Efficiency Bandwidth Product EBP
50.12

Speaker Measurement

Overall Diameter
10.7" / 274mm
Overall Depth
5.7" / 144.7mm
Front Mount Baffle Cutout
8.75" / 222mm
Mounting Depth
4.2" / 106.6mm
Motor Diameter
5.3" / 135mm
Gross Single Unit Weight (lb)
20
Single Unit Box Dimensions W x L x H (Inches)
23 x 12.75 x 7.5
Quantity of Units in Master Carton
20
Gross Master Carton Weight (lb)
41.5
Master Carton Dimensions W x L x H (Inches)
23.5 x 14 x 16

Load More

Product Overview

DS18 NXL-10M/BK

10" 2-Way Marine Water Resistant Speakers with Integrated RGB LED Lights 600W - Black

DS18’s NXL-10M’s cutting-edge design and impressive features, makes it the ultimate companion for all your marine adventures!
Built to withstand even the harshest elements, the NXL-10M’s feature a durable IP65 waterproof rating. Whether you're cruising through rough waters or battling the elements, these speakers will keep playing and delivering exceptional sound quality.
Featuring a 10-inch woofer and an integrated tweeter, the NXL-10M’s offer an impressive frequency response 35Hz – 20KHz and deliver crystal-clear sound. Experience the full depth and richness of your music in every session.
One of the standout features of the NXL-10M is its integrated RGB LED lighting system. The sleek grill design not only offers protection but also illuminates in a stunning array of colors. Customize your boat's ambiance and create a captivating atmosphere as you enjoy your favorite tunes.
DS18 has spared no expense in guaranteeing the highest quality for their marine speakers. The exclusive metal mesh grill design ensures maximum protection for your investment, while the UV-compliant materials maintain stability even under extreme conditions.
Upgrade your marine audio system with DS18’s NXL-10M and dominate the waters with superior craftsmanship and unbeatable performance.
