EXL-X 6.5" Subwoofer 400 Watts Rms DVC 4-Ohms

EXL-X 6.5" Subwoofer 400 Watts Rms DVC 4-Ohms

Name: EXL-X 6.5" Subwoofer 400 Watts Rms DVC 4-Ohms
Brand: EXL-X6.4D
SKU: EXL-X6.4D
Price: 119.95 USD
Availability: InStock
Rating: 5.0 (5 reviews)

SKU: EXL-X6.4D

$119.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

6.5" Subwoofer
MAX Power: 800 Watts
RMS Power: 400 Watts
Impedance: 4-Ohm 2" DVC
Ferrite Magnet
89.8dB

In stock

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

6.5" DIAMETER

SUBWOOFER

4+4 OHM

VOICE COIL 2"

FERRITE MAGNET

NON PRESSED PAPER + GLASS FIBER CONE

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

SPECS

SKU
EXL-X6.4D
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
4+4 ohms
RMS Power Handling
400W
Maximum Power Handling
800W
Sensitivity (1w/1m)
89.8dB
Frequency Response
40-820Hz
Recommended Lo Pass Crossover
90Hz

MOTOR

Voice Coil Diameter
2" / 50.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
SV
Cone Material
Non Pressed Paper + Glass fiber
Dust Cap Material
PPI
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
90 oz
Displacement Volume
N/A

THIELE & SMALL PARAMETERS

Equivalent Volume
2.2L / 0.078ft3
Free Air Resonance
76Hz
Mechanical Factor
4.518
Electrical Factor
0.802
Total Factor
0.681
Moving Mass
55.742g
Compliance
0.077mm/N
Bl Factor
7.3
Voice Coil Inductance
1.073mH
Diaphragm Area
143.14cm2
DC Resistance
3.2+3.2 ohm
Efficiency Bandwidth Product
94.7

RECOMMENDED ENCLOSURES

Sealed Internal Volume
0.2ft3
Sealed Box Output Response
75Hz
Ported Internal Volume
0.3ft3
Port Size *Square (W x H x Long)
0.75" x 7.24" x 10.68" / 19 x 184 x 271.2mm
Port Tuning Frequency
60Hz
Ported Box Output Response
48Hz

MEASUREMENTS

Overall Diameter
6.92" / 176mm
Overall Depth
5.15" / 131mm
Front Mount Baffle Cutout
5.78" / 147mm
Mounting Depth
4.25" / 108mm
Motor Diameter
4.96" / 126mm
Gross Single Unit Weight (lb)
10
Dimensions W x L x H (Inches)
7 x 7 x 6
Quantity of Units in Master Carton
4
Gross Master Carton Weight (lb)
20.5
M/C Dimensions W x L x H (Inches)
16 x 8 x 14

Product Overview

DS18 EXL-X6.4D

6.5" Car Subwoofer 800 Watts 4-Ohm DVC

Prepare to be blown away by the unparalleled power and precision of DS18’s EXL-X6.4D. Its incredible features and state-of-the-art design set the new standard for competition grade subwoofers.
The private red aluminum basket showcases the unmistakable flair all DS18’s products have, but also lays a great foundation for one of our most durable subwoofers yet. The fiber glass dust cap, besides adding a touch of sophistication to the already sleek design, plays a crucial role in enhancing the overall audio quality. By protecting the subwoofer's delicate components from potential damage, it ensures consistent and reliable performance.
Don't be fooled by this subwoofers size—the EXL-X6.4D is engineered to provide big bass thanks to its full-size ferrite magnet. The high-strength foam surround firmly holds a durable pressed cone made with fiberglass, resulting in unparalleled sound reproduction. And thanks to DS18's specially designed dustpan, the EXL-X6.4D’s bass output is maximized for performance that always defies expectations.
The EXL-X6.4D is designed to produce incredibly powerful and precise bass that will make your heart race. The 2" voice coils and impressive 800W MAX power handling gives the EXL-X6.4D the capability to handle frequency responses as low as 40Hz and as high as 820Hz with ease.
Versatility is key, and the EXL-X6.4D doesn't disappoint. Whether you prefer ported or sealed boxes, this subwoofer thrives in all vehicle shapes and sizes. It effortlessly adapts to your audio setup, ensuring that you can enjoy your favorite music the way it was meant to be heard—powerful, crisp, and immersive.
Unlock the true potential of your audio system with DS18’s EXL-X6.4D.

WOW

Bought from ryda.com.au wish I bought 2 now there out of stock. Send some more to ryda store in Sydney Pls DS. This fits perfectly on my Subaru Impreza Club Spec 9 the sound is amazing, good quality bass always looking forward jumping in the car and turning up the volume. Well Done Guys.

Wicked

I love these subs. I have them paired with the Exl 6.5 mids and 2" super tweeter and the sound is incredible. I am going to add the Exl 8's soon

Amazing

Kinda new to car audio, but I was looking for a smaller sub and came across the exl-x6.4. Everyone who gets in my car asks what brand of subwoofer I have and what size. When I tell them two 6.4" subs, most of them don't believe me until I show them. I purchased a pair of 6.5 midrange speaker and 2" super tweeters from DS18 previously and was so satisfied with their performance that when looking for a sub it made the most sense to come back to DS18. I'm probably a customer for life now. DS18 can expect a lot more of my money heading thier way in the future.
