DS18 has an amazing line of component sets that are sure to leave you with goosebumps when you hear the full and rich sound they produce.
The DX2 Silver line has been developed with the greatest care and over engineered to give you the highest quality along with strength that will last ages.
This set comes with the DX2W which is the 6.5 inch woofer, the DX2T 1.18" tweeter, and passive two way crossover.
The woofer comes with a sturdy carbon fiber cone and beautiful machined basket that will play clear low end music 50hz and up to 12khz with a 4 ohm impedance.
To accompany that, the tweeter will fill the gap with Crisp and clear highs so you have a complete range of frequencies and boost overall sound quality, also at 4 ohms.
The final piece of this HQ SQ component set is the included 2 way passive crossover. This crossover accurately separates wattage and frequencies for your component set and will ensure long lasting and great sounding experiences. The TW ATT options give you a selection of 0DB, 2DB, and 4DB loudness options at 12db/oct.
To be sure if you are looking for a high sound quality experience the DS18 DX2 is in your best interests!
- DX2W 6.5 inch woofer which handles 100w AES. Featuring a carbon fiber cone, machined basket, and high quality terminals.
- DX2T high fidelity tweeter that is easy to mount and will complete your HQ full range experience.
- DX2 2 way passive crossover with multiple DB selections so you can be sure to get distortion free HQ sound accurately routed to the proper speaker with ease.
|Nominal Impedance||4 OHMS|
|Peak Power Handling||400W|
|Program Power Handling||200W|
|AES Power Handling||100W|
|Sensitivity (1w/1m)||89 dB|
|Recommended HI Pass Crossover||45 Hz|
|Voice Coil Diameter||1.2”/30.5 mm|
|Voice Coil Former Material||TIL|
|Cone Material||Carbon Fiber|
|Surround Materia||Rubber Edge|
|Magnet Weight||20.2 oz|
|Overall Diameter||6.49”/165 mm|
|Front Mount Baffle Cutout||5.59”/142 mm|
|Mounting Depth||2.85”/72.5 mm|
|Nominal Impedance||4 ohms|
|Peak Power Handling||60 Watts|
|Program Power Handling||30 Watts|
|AES Power Handling||15 Watts|
|Recommended HI Pass Crossover||3.8 KHz|
|Voice Coil Diameter||0.98”|
|Voice Coil Former Material||ASV|
|Magnet Weight||14 oz|
|Overall Diameter||2” / 51mm|
|Overall Depth||1.1"/28.1 mm|
|Front Mount Baffle Cutout||1.85" x 47 mm|
|Mounting Depth||0.7” / 18 mm|
|Passive Crossover Ways||3 Ways|
|Frequency Crossover||800HZ (Mid) 3.8 Khz (Tw)|
|Power Handling||300 Watts|
|Cut Off Slope||6dB (Mid) 12dB (Tw)/ Oct|
|Tweeter Attenuation||(+/-) 3dB|
|Capacitor Type||Metac Film|
|Coil Type||. Inductor|
|Terminals Type||Screw Terminal|
|Adjustments||Tw Att Switch|
|Extra Features||Spk Phase Switch|
|Overall Length||4.3”/110 mm|
|Overall Depth||4.3”/110 mm|
|Overall Height||1.37”/35 mm|
