Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant

SKU: RZR-PROFSUB10LD

NEW ARRIVAL

Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant
Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant

Polaris RZR Pro (2020–2024) Under-Dash 10” Subwoofer Enclosure – Loaded GEN-X10.4DCF | 600W RMS, Dual 4 Ohm | IP65 Water-Resistant

SKU: RZR-PROFSUB10LD

NEW ARRIVAL

Precio de venta$599.95
/EACH
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
En stock

Channel:

Power Rating:

:

:

Color:

Cantidad:
  • Key Features

    • Engineered for Polaris RZR Pro models (2020–2024)
    • Loaded with a GEN-X10.4DCF 10" Subwoofer 600W RMS / 1200W Peak
    • Dual 4-Ohm Voice Coil Flexibility
    • IP65 Water-Resistant Design
    • Durable Performance Construction
  • Technical Data - Manual

    General Specifications

    Nominal Diameter
    10" / 254mm
    Total Impedance
    2 Ohms (Parallel)
    RMS Power Handling
    600W
    MAX Power Handling
    1200W
    Sensitivity (1w/1m)
    92dB
    Frequency Response
    25Hz-250Hz
    Recommended Low-Pass Crossover
    120Hz
    Enclosure Material
    Polyethylene (PE)
    IP Rating
    IP65
    Sold in Pair or Single
    Single
    Color / Finish
    Black
    OEM Fit
    Yes
    Compatible Model / Year
    RZR-PRO / 2020-2024 2 & 4 Doors Models
    Compatible Speaker Model
    DS18 GEN-X10.4DCF Subwoofer

    Subwoofer (GEN-X10.4DCF)

    Voice Coil Diameter
    2" / 50.8mm
    Voice Coil Former Material
    Black Aluminum
    Winding Material
    SV
    Cone Material
    Non-Pessed Paper
    Dust Cap Material
    Carbon Fiber
    Surround Material
    Rubber
    Basket Material
    Steel
    Magnet Material
    Ferrite
    Magnet Weight
    81 Oz

    Thiele & Small Parameters

    Equivalent Volume
    23.67L / 0.835ft3
    Excursion (one way)
    10.5mm
    Free Air Resonance
    37Hz
    Mechanical Factor
    5.07
    Electrical Factor
    0.76
    Total Factor
    0.66
    Moving Mass
    140.16g
    Compliance
    0.13mm/N
    BL Factor
    9.26
    Voice Coil Inductance
    0.38mH
    Diaphragm Area
    352.99cm2
    DC Resistance
    3.2 + 3.2 Ohms

    Box Specifications

    Ported Internal Volume
    25.4L / 0.9ft3
    Port Size (Diameter x Length)
    2.75" x 11.8" / 70x300mm
    Port Tuning Frequency
    36Hz
    Ported Box Output Response
    32Hz

    Box Measurement

    Overall Height
    19.8" / 504mm
    Overall Depth
    11.3" / 289mm
    Overall Width
    14" / 357mm

    Load More
  • Product Overview

    Product Overview

    Under-Dashboard 10” Subwoofer Enclosure for Polaris RZR Pro (2020–2024) Loaded with One GEN-X10.4DCF Subwoofer

    Designed for RZR Pro

    The RZR-PROFSUB10LD is a 10” subwoofer enclosure built to fit under the dashboard in Polaris RZR Pro models (2020–2024). This enclosure comes loaded with a GEN-X10.4DCF subwoofer, delivering powerful bass in a compact, vehicle-specific design.

    Bring the Bass to the Trail

    The GEN-X10.4DCF included in this enclosure is a 10” subwoofer featuring a carbon fiber dust cap and a non-pressed paper cone for improved stiffness and a sleek look. This subwoofer delivers 600W RMS power and peaks at 1200W, giving your system the low-end punch it needs on the trail.

    Seamless Compatibility

    The GEN-X10.4DCF’s dual 4Ω voice coils give you the flexibility to pair multiple subwoofers or match with a wide range of amplifiers. A durable 2" black aluminum voice coil gives this sub the strength it needs to handle high-performance audio setups.

    Ready for the Outdoors

    The RZR-PROFSUB10LD enclosure features an IP65 water-resistant rating, making it ideal for outdoor vehicles. Its black finish and direct OEM-style fit give your RZR Pro powerful bass while maintaining a clean, factory look.

    Polaris Audio Solutions

    At DS18, we focus on providing audio solutions for every type of vehicle and system. Our product lines designed specifically for Polaris vehicles ensure easy installation and seamless integration, with a look that complements your ride.

    If you're looking to get your Polaris ride loud, DS18 has you covered.
