Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono

SKU: RZR-GBSUB10LD
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono
Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono

Caja de guantera Polaris RZR, subwoofer de 10" y 1200 vatios, de fibra de carbono

SKU: RZR-GBSUB10LD

Precio de venta$659.95
/CADA
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
En stock
Cantidad:
  • Key Features

    • Caja acústica para subwoofer
    • Ajuste OEM - RZR 2014 - 2023
    • Reemplazo completo del compartimento de la guantera
    • 1 x 10" ~ 600 vatios RMS ~ 92 dB
    • Incluye accesorios de montaje y arneses Ride Command
    • Resistente al agua IP65
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS


    SKU
    RZR-GBSUB10LD
    Nominal Diameter
    10" / 254mm
    Nominal Impedance
    2 Ohms
    RMS Power Handling
    600W
    MAX Power Handling
    1200W
    Sensitivity (1w/1m)
    92dB
    Frequency Response
    25Hz-250Hz
    Recommended Low Pass Crossover
    120Hz


    Body / Features


    Enclosure Material
    Polyethylene (PE)
    Marine Grade Type
    IP65
    Sold in Pair or Single
    Single
    Color / Finish
    Black
    Port Plug Cover
    Yes (Rubber)
    Direct OEM Fit
    Yes

    Woofer Specifications


    Voice Coil Diameter
    2" / 50.8mm
    Voice Coil Former Material
    Black Aluminum
    Winding Material
    SV
    Cone Material
    Non-Pressed Paper
    Dust Cap Material
    Carbon Fiber
    Surround Material
    Rubber
    Basket Material
    Steel
    Magnet Material
    Ferrite
    Magnet Weight
    81 Oz


    Thiele & Small Parameters

    Equivalent Volume VAS
    23.67L / 0.835ft3
    Excursion (one way) XMAX
    21mm
    Free Air Resonance FS
    37Hz
    Mechanical Factor QMS
    5.07
    Electrical Factor QES
    0.76
    Total Factor QTS
    0.66
    Moving Mass MMS
    140.16g
    Compliance CMS
    0.13mm/N
    Bl Factor BI
    9.26
    Voice Coil Inductance LE
    0.38mH
    Diaphragm Area SD
    352.99cm2
    DC Resistance RE
    2.01 ohms

    Box Specifications


    Sealed Internal Volume
    25.4L / 0.9ft3
    Sealed Box Output Response F3
    64Hz
    Ported Internal Volume
    25.4L / 0.9ft3
    Port Size *Round (Diameter x Length)
    2.75" x 11.8" / 70x300mm
    Port Tuning Frequency FB
    36Hz
    Ported Box Output Response F3
    32Hz

    Box Measurement


    Overall Height
    16.9" / 430mm
    Overall Depth
    14.17" / 360mm
    Overall Wide
    16.9" / 430mm

    Load More
  • Product Overview

    Product Overview

    DS18 RZR-GBSUB10LD

    The Polaris RZR just got LOUDER with DS18’s RZR-GBSUB10LD: This 10" Loaded Subwoofer Enclosure fits perfectly in the RZR’s Glove Box and delivers powerful bass in a weather-resistant design. Its direct OEM texture and fit ensure perfect integration into your RZR, so you don’t have to think too hard when thinking outside!
    With a 10" 1200W water-resistant subwoofer, this enclosure delivers deep, impactful bass that resonates. The included mounting brackets and screws minimize the mounting depth guaranteeing a hassle-free installation with no cutting or modifications needed.
    This subwoofer enclosure has a nominal impedance of 2 ohms and RMS power handling of 600W, allowing it to handle even the most demanding systems. Its sensitivity rating of 92dB allows crystal-clear reproduction, while its frequency response of 25Hz-250Hz captures every drop accurately.
    DS18’s RZR-GBSUB10LD has a range of impressive features: like the included port plug cover, adding an extra layer of protection when not in use. Or the enclosure material, also made from durable polyethylene (PE) and marine-grade IP65 rated, providing excellent protection against the elements on any trail!
    Provided are two Ride Command Harnesses to connect the RZR-GBSUB10LD to your RZR’s Ride Command Center for easy amplifier installation. One comes with a remote and RCA output: this is used for your subwoofer. The other harness is a full range audio output used for audio signal only.
    Get LOUD off-road like never before with DS18’s RZR-GBSUB10LD!
