DS18 HOOLIGAN X Black Frame, High Excursion 12" audio Subwoofer 4000 Watts RMS 4" DVC 2-Ohms
HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm
HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm
HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm
HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm
HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm

HOOLIGAN X 12" High Excursion Subwoofer 4000 Watts Rms 4" DVC 2-Ohm

SKU: HOOL-X12.2DHE

Sale price$699.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 12" High Excursion Subwoofer
  • MAX Power: 6000 Watts
  • RMS Power: 4000 Watts
  • Impedance: 2-Ohm 4" DVC
  • Ferrite Magnet
  • 87dB
In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

12

12" DIAMETER

SUBWOOFER

SUBWOOFER

2+2 OHM

2+2 OHM

VOICE COIL 4

VOICE COIL 4"

FERRITE MAGNET

FERRITE MAGNET

HIGH EXCURSION SURROUND

HIGH EXCURSION SURROUND

DOWNLOAD THE USER MANUAL

SPECS

SKU
HOOL-X12.2DHE
Nominal Diameter
12" / 304.8mm
Nominal Impedance
2+2 ohms
RMS Power Handling
4000W
MAX Power Handling
6000W
Sensitivity (1w/1m)
87dB
Frequency Response
20-500Hz
Recommended Lo Pass Crossover
80Hz

MOTOR

Voice Coil Diameter
4” / 99.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
Carbon Fiber
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Gloss Black with Machined Aluminum
Magnet Material
Ferrite
Magnet Weight
500 OZ
Displacement Volume
4.8L / 0.169ft3

THIELE & SMALL PARAMETERS

Equivalent Volume
22.57L / 0.79ft3
Free Air Resonance
26Hz
Mechanical Factor
2.778
Electrical Factor
0.489
Total Factor
0.462
Moving Mass
512.12g
Compliance
0.072mm/N
Bl Factor
24.27
Voice Coil Inductance
42.29mH
Diaphragm Area
471.44cm2
DC Resistance
1.8+1.8 ohms
Efficiency Bandwidth Product
53.1

RECOMMENDED ENCLOSURES

Sealed Internal Volume
17L / 0.6ft3
Sealed Box Output Response
41Hz
Ported Internal Volume
42.5L / 1.5ft3
Port Size *Square (W x H x Long)
1.52" x 12.28" x 31.82" / 38.5 x 312 x 808.2 mm
Port Tunning Frequency
30Hz
Ported Box Output Response
25Hz

MEASUREMENT

Overall Diameter
12.64" / 321mm
Overall Depth
11.6" / 295mm
Front Mount Baffle Cutout
11.2" / 285mm
Mounting Depth
10" / 255mm
Motor Diameter
9.96” / 253mm
Product Weight (lb)
87.5
Dimensions L x W x H (Inches)
15 x 15 x 14
M/C Weight (lb)
87.5
M/C Dimensions L x W x H (Inches)
15 x 15 x 14
M/C Qty
1
Sold in
Single

Load More

Product Overview

DS18 HOOL-X12.2DHE

HOOLIGAN 12" High Excursion Car Subwoofer 4000 Watts Rms 4" DVC 2-Ohm

Experience a new level of bass performance and power with DS18’s HOOL-X12.2DHE! The HOOLIGAN 12” High Excursion Car Subwoofer has been the top choice for enthusiasts and competitors alike, and now, it’s back with a vengeance.
The HOOLIGAN is built for power and durability. The redesigned long throw pole, larger spider, and high excursion surround, helps lower the HOOLIGAN’s FS (Resonant Frequency), making it even louder at subsonic frequencies. With an FS of 26, this subwoofer guarantees impressive low frequencies all the way down to 20Hz. Its high-powered 4" Black Aluminum voice coil can handle 4000W RMS and 6000W MAX power, making it perfect for heavy-hitting competition bass.
Versatility is key, and the HOOL-X12.2DHE can adapt to various enclosure types. Whether you prefer 4th orders, 6th orders, ported boxes, or large sealed boxes, this subwoofer will thrive in any setup that has enough room.
This version of the HOOLIGAN boasts a nominal diameter of 12" (304.8 mm) and a nominal impedance of 2+2 OHMS to amplify the performance and capabilities of this high-powered subwoofer. With a sensitivity of 87 dB and a frequency response ranging from 20Hz to 500Hz, this subwoofer ensures every beat is reproduced with staggering depth and precision.
DS18’s HOOLIGAN 12" High Excursion Car Subwoofer is the ultimate choice for car audio enthusiasts seeking extreme bass and massive power. Its unmatched performance, cutting-edge design, and versatility make it a must-have for any ground shaking audio system.
