GEN-XX 12" High Excursion Subwoofer Double Stacked Magnets 600 Watts Rms DVC 4-Ohm

SKU: GEN-XX12.4DHE
DS18 GEN-XX 12" High Excursion Subwoofer 1200 Watts DVC 4-Ohms audio subwoofers. x x 12.
DS18 GEN-XX 12" High Excursion Subwoofer 1200 Watts DVC 4-Ohms audio subwoofers. x x 12.
GEN-XX 12" High Excursion Subwoofer Double Stacked Magnets 600 Watts Rms DVC  4-Ohm
DS18 GEN-XX 12" High Excursion Subwoofer 1200 Watts DVC 4-Ohms audio subwoofers. x x 12.
DS18 GEN-XX 12" High Excursion Subwoofer 1200 Watts DVC 4-Ohms audio subwoofers. x x 12.
GEN-XX 12" High Excursion Subwoofer Double Stacked Magnets 600 Watts Rms DVC  4-Ohm

GEN-XX 12" High Excursion Subwoofer Double Stacked Magnets 600 Watts Rms DVC 4-Ohm

SKU: GEN-XX12.4DHE

Sale price$149.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock
Quantity:
  • Key Features

    • 12" High Excursion Subwoofer
    • MAX Power: 1200 Watts
    • RMS Power: 600 Watts
    • Impedance: 4-Ohm 2" DVC
    • Ferrite Magnet
    • 86.7dB
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    GEN-XX12.4DHE
    Nominal Diameter
    12"
    Nominal Impedance
    4+4 Ohm
    RMS Power Handling
    600W
    Maximum Power Handling
    1200W
    Sensitivity (1w/1m)
    86.7 dB
    Frequency Response
    20Hz - 1.5Khz
    Recommended Lo Pass Crossover
    80Hz

    MOTOR

    Voice Coil Diameter
    2" / 50.8 mm
    Voice Coil Former Material
    Black Aluminum
    Winding Material
    SV
    Cone Material
    Paper
    Dust Cap Material
    PPI
    Surround Material
    Foam
    Basket Material
    Steel Bakset
    Basket Color/Finish
    Glossy Red
    Magnet Material
    Ferrite
    Magnet Weight
    136 oz
    Displacement Volume
    1.69L

    THIELE & SMALL PARAMETERS

    Equivalent Volume Vas
    56.436 L
    Free Air Resonance Fs
    30.5 Hz
    Mechanical Factor Qms
    3.991
    Electrical Factor Qes
    0.532
    Total Factor Qts
    0.469
    Moving Mass Mms
    154.38g
    Compliance Cms
    0.175mm/N
    Bl Factor BI
    19.173N/A
    Voice Coil Inductance Le
    0.6741mH
    Diaphragm Area Sd
    475.29cm2
    DC Resistance Re
    3.2+3.2 ohms
    Efficiency Bandwidth Product EBP
    57.3

    MEASUREMENTS

    Overall Diameter
    12.44" / 316mm
    Overall Depth
    7.6" / 193mm
    Front Mount Baffle Cutout
    10.9" / 277mm
    Mounting Depth
    6.5" / 165mm
    Motor Diameter
    6.14"/ 156 mm
    Gross Single Unit Weight (lb)
    19.5
    Dimensions W x L x H (Inches)
    13.5 x 13.5 x 9
    Quantity of Units in Master Carton
    2
    Gross Master Carton Weight (lb)
    41.5
    M/C Dimensions W x L x H (Inches)
    14.25 x 14.25 x 19

    Load More
  • Product Overview

    Product Overview

    DS18 GEN-XX12.4DHE

    12" High Excursion Car Subwoofer 1200 Watts 4-Ohm DVC Double Magnet

    Introducing the DS18 GEN-XX12.4DHE, a game-changer in the world of car audio, offering unparalleled low-frequency performance at an affordable price. With the GEN-XX12.4DHE, you can now experience that heart-pounding sensation of concert-quality deep thumping bass right in the comfort of your car.
    Crafted with the finest materials, the GEN-XX12.4DHE exemplifies professional quality and unmatched durability. The black aluminum voice coil former, paper cone, and foam surround work harmoniously to deliver exceptional performance and withstand the test of time. The glossy red steel basket adds a touch of elegance to your car's interior.
    Featuring a remarkable power rating of 600W RMS and 1200W maximum, the GEN-XX12.4DHE doesn't require massive amounts of power to deliver a mind-blowing performance. You'll be able to shake the neighborhood and turn heads wherever you go without breaking the bank. The GEN-XX12.4DHE’s frequency response of 20Hz to 1.5KHz guarantees a wide range of bass reproduction, allowing you to hear every detail and nuance of your favorite tracks.
    The long 2-inch voice coil and double magnet are specifically designed to ensure that every note is reproduced with exceptional clarity and precision. With a low FS of 30.5 Hz, the GEN-XX12.4DHE effortlessly reaches into the subsonic range, giving you the ability to experience those earth-shaking frequencies without any issues, if your box is correctly tuned.
    Get ready to redefine what you thought was possible in car audio – the GEN-XX12.4DHE is here to make your dreams a reality.
