DS18 PRO-NS8 8" Shallow Neodymium Mid-Range Loudspeaker 400 Watts 8-Ohm

Shop online DS18 PRO 8" Shallow Neodymium Mid-Range Loudspeaker 8-Ohms Audio Midrange speakers

PRO-NS8

DS18 PRO-NS8 8" Shallow Neodymium Mid-Range Loudspeaker 400 Watts 8-Ohm

Name: DS18 PRO-NS8 8" Shallow Neodymium Mid-Range Loudspeaker 400 Watts 8-Ohm
Brand: PRO-NS8
SKU: PRO-NS8
Price: 72.95 USD
Availability: InStock

Over 301 Sold

PRO-NS8

$72.95

/ EACH

Quantity

FAST FREE SHIPPING

2 YEAR WARRANTY

30-DAY RETURNS

FINANCING SOLUTIONS

Have a Question? Ask a Specialist
305-928-8734 / Live Chat

FAST FREE SHIPPING

2 YEAR WARRANTY

30-DAY RETURNS

FINANCING SOLUTIONS

Overview
Technical Details
Buy This With
Reviews

Overview

DS18's new Neodymium shallow speakers were designed to give you maximum loudness and volume all while keeping a nice small framed package. Most neo speakers are full size and take up a good amount of mounting depth, with these new Neo slim speakers, you can get that insane neodymium loudness where there is not much room for full size speakers.

This 8" inch neodymium 2" voice coil Midrange speaker takes 200w RMS and 400w Peak power, so you know they will get loud easily. The 96dB sensitivity rating will be sure to give you plenty of volume as well for years and years of enjoyment.

Highlights

Neodymium Slim design so now you can get all that neodymium power and volume in a slim frame.
High efficiency 8 ohm 2 inch voice coil that handles 200w RMS and 400w peak power for extreme loudness and frequency precision.
Shallow mounting depth of only 2.48 inches, these neodymium midrange speakers can fit almost anywhere you need great sound and max volume.

shallow neodymium mid-range loudspeaker

Technical Details

PRO-NS8 Product Manual

Nominal Diameter	8"/208mm
Nominal Impedance	8 Ohms
RMS Power Handling	200W
MAX Power Handling	400W
Sensitivity (1w/1m)	96 dB
Frequency Response	97Hz - 12KHz
Recommended Hi Pass Crossover	160Hz
Pair or Single	Single

Voice Coil Diameter	2"/50.8mm
Voice Coil Former Material	KSV
Winding Material	Copper
Cone Material	Paper
Dust Cap Material	paper
Surround Materia	Cloth
Basket Material	Steel
Basket Color	Glossy Red
Magnet Material	Neodymium
Magnet Weight	3.32oz
THIELE & SMALL PARAMETERS
Equivalent Volume	5.48l / 0.193ft3
Excursion (one way)	2 mm
Free Air Resonance	120Hz
Mechanical Factor	3.781
Electrical Factor	0.952
Total Factor	0.761
Mechanical Mass	13.242g
Mechanical Compliance	162m cm/N
BL Factor	6.029
Voice Coil Inductance	7.011mH
Cone Area	213.825 Cm3
DC Resistance	6.5 ohms
Mechanical Mass w/o air/	13.07g
MEASUREMENTS
Overall Diameter	8.2"
Overall Depth	2.67"
Front Mount Baffle Cutout	7.12"
Mounting Depth	2.48"
Motor Diameter	4.33"
