DS18 PRO-GM8SE 8" Sealed Back Mid-Range Loudspeaker 580 Watts 8-Ohm
SOLD OUT
DS18 PRO-GM8SE 8" Sealed Back Mid-Range Loudspeaker 580 Watts 8-Ohm
SOLD OUT
Sale $35.66 / EACH
Reg.$41.95
15% OFF FOR Labor Day Sale!
-
Key Features
- 8" Mid-Range
- MAX Power: 580 Watts
- RMS Power: 190 Watts
- Impedance: 8-Ohm
- Ferrite Magnet
- Sealed Back
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSpecifications
SKU
PRO-GM8SE
Nominal Diameter
8" / 203.2mm
Nominal Impedance
8 Ohm
RMS Power Handling
190W
MAX Power Handling
580W
Sensitivity (1w/1m)
96dB
Frequency Response
250Hz-10KHz
Recommended HI Pass Crossover
350 Hz
Pair or Single
Single
Grill Included
No
Motor
Voice Coil Diameter
1.5" / 38.1mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
Paper
Bullet Material / Color
N/A
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Matte Black
Magnet Material
Ferrite
Magnet Weight
30 oz
Thiele & Small Parameters
Equivalent Volume (Vas)
1.25L / 0.44ft3
Excursion (one way) (Xmax)
N/A
Free Air Resonance (Fs)
448Hz
Mechanical Factor (Qms)
8.336
Electrical Factor (Qes)
4.402
Total Factor (Qts)
2.88
Mechanical Mass (Mms)
6.922g
Mechanical Compliance (Cms)
0.018mm/N
BL Factor (BL)
5.29
Voice Coil Inductance (Le)
0.736mH
Cone Area (Sd)
221.67cm2
DC Resistance (Re)
6.3 ohm
Measurement
Overall Diameter
8.26" / 210 mm
Overall Depth
3.46" / 88 mm
Front Mount Baffle Cutout
7.2" / 183 mm
Mounting Depth
3.22" / 82mm
Motor Diameter
4.72" / 120mm
Gross Single Unit Weight (lb)
5
Single Unit Box Dimensions W x L x H (Inches)
9 x 9 x 4
Quantity of Units in Master Carton
8
Gross Master Carton Weight (lb)
40
Master Carton Dimensions W x L x H (Inches)
18.5 x 18.5 x 8.8
-
Product Overview
Product Overview
DS18 PRO-GM8SE 8” Sealed Back Mid-Range Loudspeaker 580W 8-Ohm
At the heart of every incredible sound system lies a mid-range driver, responsible for reproducing the most crucial frequencies in every song. The PRO-GM8SE, with its impeccable design and near perfect midrange frequency reproduction, redefines everything you know about mid-range performance.
The PRO-GM series, an evolution of DS18's celebrated GEN Series, stands as a testament to the brand's commitment to audio excellence. Crafted with meticulous precision, the PRO-GM midranges boast black color steel baskets that exude both elegance and durability. And with the freedom to choose between classic, bullet, or sealed back configurations, you have the power to customize your sound to perfection.
One of the standout features of the PRO-GM8SE is its ingenious sealed back design, which grants you the freedom to install these exceptional drivers in boxes with high turbulence or pressure without the risk of damaging their delicate cones.
With an RMS power of 190W and a staggering max power of 580W, these drivers are easily propelled to insane volume. The frequency response, spanning from 250Hz to 10kHz, captures every nuance and subtlety of your favorite tracks, while the 8-ohm impedance and high sensitivity of 96dB guarantee an optimal power transfer and efficient sound reproduction. Seamlessly blending power and sensitivity, these midrange frequencies will pierce through the bass and midrange, painting a rich soundstage that will leave you in awe every session.
Installing the PRO-GM8SE is a breeze, thanks to its manageable dimensions. With a 1.5" voice coil size, a 3.22" mounting depth, and a 7.2" (145mm) cut-out dimension, you have the flexibility to seamlessly integrate these drivers into your existing setup without compromise.
