PANCADÃO Mid-Bass Loudspeaker 12" 3000 Watts Rms 8-Ohm

PANCADÃO Mid-Bass Loudspeaker 12" 3000 Watts Rms 8-Ohm

Name: PANCADÃO Mid-Bass Loudspeaker 12" 3000 Watts Rms 8-Ohm
Brand: PRO-3KP12.8
SKU: PRO-3KP12.8
Price: 479.95 USD
Availability: OutOfStock

SKU: PRO-3KP12.8

SOLD OUT

$479.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

12" Mid-Bass
MAX Power: 6000 Watts
RMS Power: 3000 Watts
Impedance: 8-Ohm
Ferrite Magnet
95dB

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

12" DIAMETER

MID-BASS

8 OHM

Non-Pressed Paper Cone

ALUMINUM BASKET

FERRITE MAGNET

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

SPECS

SKU
PRO-3KP12.8
Nominal Diameter
12" / 304mm
Nominal Impedance
8 ohm
RMS Power Handling
3000W
MAX Power Handling
6000W
Sensitivity (1w/1m)
95dB
Frequency Response
45Hz-3KHz
Recommended HI Pass Crossover
70Hz
Sold in Pair or Single
Single
Grill Included
No

Motor

Voice Coil Diameter
4" / 101.6mm
Voice Coil Former Material
Fiber Glass
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
Paper
Surround Material
Cloth
Basket Material
Aluminum
Basket Color/Finish
Black
Magnet Material
Ferrite
Magnet Weight
250 oz
Displacement Volume
3.98L / 0.14ft3

Thiele & Small Parameters

Equivalent Volume Vas
25L / 0.88ft3
Excursion (one way) Xmax
7mm
Free Air Resonance Fs
62Hz
Mechanical Factor Qms
2.084
Electrical Factor Qes
0.377
Total Factor Qts
0.32
Mechanical Mass Mms
113.1g
Mechanical Compliance Cms
56.12 mm/N
BL Factor BL
18.5
Voice Coil Inductance Le
621 mH
Cone Area Sd
510.71 cm2
DC Resistance Re
5.6 ohms
Efficiency Bandwidth Product EBP
159

Recommended Enclosures

Ported Internal Volume
50L / 1.78ft3
Port Size *Square (WxHxLong)
4.72" x 12.8" x 9" / 120 x 325 x 230mm
Port Tunning Frequency Fb
76Hz
Ported Box Output Response F3
65Hz

Measurement

Overall Diameter
12.36" / 314mm
Overall Depth
7.75" / 197mm
Front Mount Baffle Cutout
11.18" / 284mm
Mounting Depth
7.2" / 183mm
Motor Diameter
8.66" / 220mm

Shipping Info

Gross Single Unit Weight
51
Single Unit Box Dimensions L x W x H (Inches)
15 x 15 x 11
Quantity of Units in Master Carton
1
Gross Master Carton Weight
51
Master Carton Dimensions L x W x H (Inches)
15 x 15 x 11

Product Overview

DS18 PRO-3KP12.8

Prepare to be blown away by DS18’s PRO-3KP12.8 PANCADÃO Mid-Bass Loudspeaker - the ultimate addition to any high-performance pro audio system. This speaker is not for the faint-hearted. With a name that means "strong beat" in Brazilian Portuguese, this speaker delivers just that.
Featuring a large high-strength ferrite magnet and reinforced aluminum basket, the PRO-3KP12.8 is built to handle insane amounts of power and get LOUD like no other. Its 3000 Watts RMS Power Handling and 6000 Watts MAX Power Handling make it one of the most powerful mid-bass speakers on the market.
But that's not all - this speaker is a true "do-all" woofer, capable of playing an incredible range of frequencies from hard-punching mid-bass to mid-high vocals, all at an unbelievable volume. With a sensitivity of 95dB and a frequency response of 45Hz-3KHz, the PRO-3KP12.8 sets a new standard for sound quality.
DS18’s PRO-3KP12.8 PANCADÃO Mid-Bass Loudspeaker is designed to be versatile enough to fit in any sound system, and this is further emphasized by the range of impedances available for this speaker. The PRO-3KP12.8 is offered in a 8-Ohm configuration, which makes it compatible with a wide range of amplifiers and audio systems, but these speakers also come in 4-ohm and 2-ohm configurations. This flexibility in impedance options allows the speaker to work seamlessly with different audio setups, ensuring that you get the best performance out of your sound system.
If you're looking for a speaker that will set your sound system apart from the rest, look no further than DS18’s PRO-3KP12.
