PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm
PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm
PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm
PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm
PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm
PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm

PANCADÃO Mid-Bass Loudspeaker 12" 1500 Watts Rms 4-Ohm

SKU: PRO-1.5KP12.4

Sale price$399.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
  • 12" Mid-Bass
  • MAX Power: 3000 Watts
  • RMS Power: 1500 Watts
  • Impedance: 4-Ohm
  • Ferrite Magnet
  • 96.5dB
In stock
Quantity:

Have a Question? Ask a Specialist 305-928-8734 / Live Chat

FAST FREE SHIPPING
30-DAY RETURNS
2 YEAR WARRANTY
SECURE PAYMENT

KEY FEATURES

12

12" DIAMETER

MID-BASS

MID-BASS

4 OHM

4 OHM

PAPER CONE

PAPER CONE

ALUMINUM BASKET

ALUMINUM BASKET

FERRITE MAGNET

FERRITE MAGNET

DOWNLOAD THE USER MANUAL

SPECS

SKU
PRO-1.5KP12.4
Nominal Diameter
12"
Nominal Impedance
4 ohms
RMS Power Handling
1500 Watts
MAX Power Handling
3000 Watts
Sensitivity (1w/1m)
96.5 dB
Frequency Response
50Hz-2KHz
Recommended HI Pass Crossover
60 Hz
Pair or Single
Single
Grill Included
No

Motor

Voice Coil Diameter
4"
Voice Coil Former Material
Fiber Glass
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
PAPER
Bullet Material
N/A
Surround Material
Cloth
Basket Material
Aluminum
Magnet Material
Ferrite
Magnet Weight
150 oz

Thiele & Small Parameters

Equivalent Volume Vas
22.775 L
Free Air Resonance Fs
72.4 Hz
Mechanical Factor Qms
9.451
Electrical Factor Qes
0.301
Total Factor Qts
0.291
Mechanical Mass Mms
51.09
Mechanical Compliance Cms
70.323 mm/N
BL Factor BL
15.144
Voice Coil Inductance Le
1.566MH
Cone Area Sd
560 cm2
CD Resistance Re
1.6 ohm
Efficiency Bandwidth Product EBP
240

Measurement

Overall Diameter
12.36" / 314 mm
Overall Depth
6.53" / 166 mm
Front Mount Baffle Cutout
11.18" / 284 mm
Mounting Depth
5.98" / 152 mm
Motor Diameter
8.66" / 220 mm

Load More

Product Overview

DS18 PRO-1.5KP12.4

12” PANCADAO Mid-Bass Loudspeaker 1500W RMS 4-Ohm

Prepare to be blown away by the DS18 PRO-1.5KP12.4 PANCADÃO Mid-Bass Loudspeaker - the ultimate addition to any high-performance pro audio system. This speaker is not for the faint-hearted. With a name that means "hard-hitting bass" in Brazilian Portuguese, this speaker delivers just that.
Featuring a large high-strength ferrite magnet and reinforced aluminum basket, the PRO-1.5KP12.4 is built to handle insane amounts of power and get LOUD like no other. Its 1500 Watts RMS Power Handling and 3000 Watts MAX Power Handling make it one of the most powerful mid-bass speakers on the market.
But that's not all - this speaker is a true "do-all" woofer, capable of playing an incredible range of frequencies from hard-punching mid-bass to mid-high vocals, all at an unbelievable volume. With a sensitivity of 99.2 dB and a frequency response of 45Hz-10kHz, the PRO-1.5KP12.4 sets a new standard for sound quality.
The DS18 PRO-1.5KP12.4 PANCADÃO Mid-Bass Loudspeaker is designed to be versatile enough to fit in any sound system, and this is further emphasized by the range of impedances available for this speaker. The PRO-1.5KP12.4 is offered in a 4-Ohm configuration, which makes it compatible with a wide range of amplifiers and audio systems, but these speakers also come in 2-ohm and 8-ohm configurations. This flexibility in impedance options allows the speaker to work seamlessly with different audio setups, ensuring that you get the best performance out of your sound system.
If you're looking for a speaker that will set your sound system apart from the rest, look no further than the DS18 PRO-1.5KP12.4 PANCADÃO Mid-Bass Loudspeaker.
