DS18 PRO 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8-Ohms Midrange car audio stereo speakers
DS18 PRO-XLNEO12MB 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8 Ohm
DS18 PRO-XLNEO12MB 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8 Ohm
DS18 PRO-XLNEO12MB 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8 Ohm
DS18 PRO 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8-Ohms Midrange car audio stereo speakers
DS18 PRO 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8-Ohms Midrange car audio stereo speakers

DS18 PRO-XLNEO12MB 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8 Ohm

shipping-truck
Ships Free Next Business Day
With some limitations - subject to verification and order volume

PRO-XLNEO12MB

Regular price $299.95EACH
/
FAST FREE SHIPPING
2 YEAR WARRANTY
30-DAY RETURNS
FINANCING SOLUTIONS

Have a Question? Ask a Specialist
305-928-8734
 / Live Chat

FAST FREE SHIPPING
2 YEAR WARRANTY
30-DAY RETURNS
FINANCING SOLUTIONS

DS18 PRO-XLNEO12MB 12" Neodymium Mid-Bass Loudspeaker 1000 Watts RMS 8 Ohm

Our newest addition just came raging into our massive pro audio line, the PRO-XLNEO12MB! This monster mid-bass speaker is backed by the full power of neodymium technology, which helps this mammoth mid-bass speaker handle more power, handle that power more efficiently, operate cooler, and are overall lighter than traditional ferrite motors. This mid-bass is great for those wanting to bring frequencies of 50+Hz with authority and full volume to accompany all your other frequencies for an amazing sound quality and full audio range. This neo mid-bass speaker comes with a gigantic 4 inch voice coil that handles 1000w RMS and 2000w max power so you can be sure that your mid-bass will turn all heads in a crowd!

Highlights

  • 12 inch mid-bass speaker that provides great cone area so you can achieve that thumping mid-bass with the correct amp to power them.
  • Huge 4 inch voice coil which handles a staggering 1000w RMS and 2000w Peak power to really power through the music.
  • Neodymium design allows the speaker to handle more wattage more efficiently, while also being lighter and running cooler than traditional ferrite motor structures.

ds18 neodymium mid-bass loudspeaker 1000 watts

ds18 neodymium mid-bass loudspeaker 1000 watts

ds18 neodymium mid-bass loudspeaker 1000 watts

ds18 neodymium mid-bass loudspeaker 1000 watts

ds18 neodymium mid-bass loudspeaker 1000 watts

PRO-XLNEO12MB Product Manual
RMS Power Handling@8 OHMS 1000W
MAX Power Handling@8 OHMS 2000W
Sensitivity (1w/1m) 98.2 dB
Frequency Response 45Hz - 7KHz
Recommended HI Pass Crossover 80Hz
Pair or Single Single
MOTOR
Voice Coil Diameter 4” / 99.8mm
VC Former Material Glass Fiber
Winding Material CCAW
Cone Material Paper
Dustcap Material Paper
Surround Materia Cloth
Basket Material Aluminum
Basket Color Sandblasted Black
Magnet Material Neodymium
Magnet Weight 18.5 Oz
Displacement Volume 2.32L / 0.082ft3
THIELE & SMALL PARAMETERS
Equivalent Volume Vas: 22.76L / 0.8ft3
Excursion (one way) Xmax: 13.8 mm
Free Air Resonance Fs: 72Hz
Mechanical Factor Qms: 1.61
Electrical Factor Qes: 0.359
Total Factor Qts: 0.294
Mechanical Mass Mms: 83.362g
Mechanical Compliance Cms: 0.059mm/N
BL Factor Bl: 23.553
Voice Coil Inductance Le: 32.64mH
Cone Area Sd: 522.79CM²
DC Resistance Re: 5.2 Ohm
Mechanical Mass w/o Air Mmd: 69.855g
MEASUREMENTS
Overall Diameter 12.32“ / 313mm
Overall Depth 5.92” / 150.5mm
Front Mount Baffle Cutout 11.2“ / 284.5mm
Mounting Depth 5.45” / 138.5mm
Motor Diameter 5.86”/149mm
