ZXI 1-Channel Class D Amplifier 3000 Watts Rms @ 1-ohm
ZXI 1-Channel Class D Amplifier 3000 Watts Rms @ 1-ohm
Sale $601.76 / EACH
Reg.$707.95
15% OFF FOR Labor Day Sale!
Availability:15 Items
-
Key Features
- 1 Channel Subwoofer Monoblock
- Class D
- 1 ~ 4 Ohm Stable
- 1 x 3000 Watts @ 1 Ohm
- Built in Crossover
- Bass Control Knob
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
Load More Show LessSPECS
SKU
ZXI.1XXL
Total Watts (Peak)
9000W
RMS Power @ 4 Ohm
1500W
RMS Power @ 2 Ohm
2400W
RMS Power @ 1 Ohm
3000W
RMS Power @ 4 Ohm Bridge
N/A
Audio
Frequency Response
20Hz-500Hz
Signal to Noise Ratio
>87dB
Efficiency @ 4 Ohm
>80%
Damping Factor
>250
Total Harmonic Distortion (THD)
<0.1%
Low Level Input Range
0.2 - 6v
High Level Input
No
Selectable X-Over
LPF (Fixed)
X-Over Filter Range
50Hz-250Hz
Bass Boost Range
0-18dB
Bass Boost Frequency
45Hz
Infrasonic Filter
10-55Hz
Phase Selector
0-180°
Features
Amplifier Class
Digital
Amplifier Type
Monoblock Subwoofer
Number of Channels
1
Minimum Impedance
1 ohm
Led Indicator
Power/Protection/Clip
Power Input Terminal Size
0ga
Fuse Size
300A (External)
Remote Level Control
Yes
Cooling Fan
No
Voltmeter
No
Thermal Protection
Yes (>160?F / 71?C)
Over-Load Protection
Yes
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (8.5-16.8V)
Cliping Protection
Yes
Body Color / Finish
Black Aluminum Brush
Extra Features
Tiffany RCA connectors
Yes
Input Selector
N/A
Compact Size to easy Installation for Any Applications
Yes
Stable/Reliable Two Layers Traces PCB Design
Yes
Quality Control Verification using Audio Precision Instruments
Yes
Measurement
Overall Length
15.4" / 391mm
Overall Width
5.66" / 144mm
Overall Height
1.9" / 48.5mm
Heatsink Length
14.6" / 371mm
Gross Single Unit Weight (Lb)
9.5
-
Product Overview
Product Overview
DS18 ZXI.1XXL 1-Channel Class D Amplifier 3000 Watts x 1 @ 1 Ohm RMS
In the world of car audio, evolution is inevitable, and DS18 understands this better than anyone else. We proudly present the ZXI.1XXL, a new echelon of audio excellence for our legendary Z series amplifiers.
DS18’s ZXI.1XXL is more than just an amplifier; it's an elegantly designed powerhouse that effortlessly blends power with space saving efficiency. The monoblock design of the ZXI.1XXL packs colossal power into a compact package, making it an ideal choice for those who demand big sound without sacrificing space.
This amplifier delivers 1500W at 4 ohms, 2400W at 2 ohms, and a staggering 3000W at 1 ohm, making it compatible with a wide range of setups. The ZXI.1XXL flexes its muscles with unparalleled authority. Feel the thunderous bass, crystal-clear mids, and soaring highs as you've never experienced before. With a frequency response spanning from 20Hz to 500kHz and a minuscule THD of just 0.10%, the ZXI.1XXL is guaranteed to put that power to good use.
Tuning your audio system has never been easier. The DS18 ZXI.1XXL allows you to expertly tune your music to your preferences, putting the power to create your perfect soundstage right at your fingertips. Immerse yourself in your music with precision tuning controls. The included bass knob allows you to tailor your bass response from song to song with surgical accuracy, while the bass boost, frequency adjust, and phase controls ensure distortion-free sound.
Elevate your car audio to legendary status with DS18’s ZXI.1XXL. Your ears deserve nothing less.
