2" Encapsulated Dome Tweeter With Ceramic Diaphragm & External Crossover







2" Encapsulated Dome Tweeter With Ceramic Diaphragm & External Crossover
Sale $339.96 / PAIR
Reg.$399.95
15% OFF FOR MOVING SALE!
-
Key Features
- 2" Encapsulated Tweeter with External Crossover
- RMS Power: 50 Watts(100 Watts Peak)
- Impedance: 4 Ohm ~ 88dB
- Ceramic Diaphragm
- Neodymium Magnet
- Pair
-
Technical Data - Manual
DOWNLOAD THE USER MANUAL
SPECS
SKU
DXTC
Nominal Diameter
2" / 51mm
Nominal Impedance
4 Ohms
AES Power Handling
25W
Program Power Handling
50W
Peak Power Handling
100W
Sensitivity (1w/1m)
88dB
Frequency Response
250Hz-20KHz
Recommended Hi Pass Crossover
500Hz
Sold In Pair or Single
Pair
Body / Features
Crossover (Bass Blocker)
External / 12dB/Oct
Body Material
CNC Aluminum
Body Color / Finish
Black
Faceplate Color / Finish
Black
Motor
Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
Polyimide
Winding Material
Aluminum
Diaphragm Material
Ceramic
Magnet Material
Neodymium
Magnet Size / Weight
25mm / 0.65Oz
Measurement (Tweeter)
Overall Diameter
2.36" / 60mm
Overall Depth
2" / 52mm
Front Mount Baffle Cutout
2" / 52mm
Mounting Depth
1.4" / 36mm
Measurement (Crossover)
Overall Length
3.15" / 78mm
Overall Width
1.95" / 49.5mm
Overall Height
1.14" / 29mm
-
Product Overview
Product Overview
DS18 DXTC Designed for audiophiles who demand nothing but the best, DS18’s DXTC transforms your vehicle into a concert hall on wheels.
Built to deliver crisp, clear high frequencies, DS18’s DXTC tweeter operates at an impedance of 4 ohms with power handling capabilities that range from 25W AES to a peak of 100W (40 – 50W RMS Recommended), for distortion-free performance. The tweeter’s sensitivity of 88dB and frequency response spanning from 250Hz to 20KHz guarantees well-rounded sound every session.
The included passive crossover is designed to filter out damaging bass frequencies, protecting the tweeters and preserving their clarity. This 12dB/Oct crossover is compact yet powerful, making it easy to integrate into any car audio setup.
The tweeter’s ceramic diaphragm and neodymium magnet ensure longevity and superior sound quality, while the polyimide voice coil former and aluminum winding materials add to its durability.
Whether you’re upgrading an existing system or building a new one from scratch, DS18’s DXTC is essential for any serious enthusiast.
