DS18 PRO-B6.4 6.5" Mid-Range Car Audio Loudspeaker with Bullet 4-Ohm 120 Watts.

DS18 PRO-B6.4 6.5" Mid-Range Car Audio Loudspeaker with Bullet 120 Watts 4-Ohm

DS18 PRO-B6.4 6.5" Mid-Range Car Audio Loudspeaker with Bullet 120 Watts 4-Ohm

Name: DS18 PRO-B6.4 6.5" Mid-Range Car Audio Loudspeaker with Bullet 120 Watts 4-Ohm
Brand: PRO-B6.4
SKU: PRO-B6.4
Price: 26.99 USD
Availability: OutOfStock
Rating: 5.0 (1 reviews)

SKU: PRO-B6.4

SOLD OUT

$26.99

/EACH

Ships Free Next Business Day From Miami, FL, USA

6.5" Mid-Range
MAX Power: 120 Watts
RMS Power: 60 Watts
Impedance: 4-Ohm
Ferrite Magnet
With Bullet

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

6.5" DIAMETER

MID-RANGE

4 OHM

ABS BULLET

STEEL BASKET

FERRITE MAGNET

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

Specifications

SKU
PRO-B6.4
Nominal Diameter
6.5" / 165mm
Nominal Impedance
4 Ohm
RMS Power Handling
60W
MAX Power Handling
120W
Sensitivity (1w/1m)
93.4dB
Frequency Response
100Hz - 12.5KHz
Recommended HI Pass Crossover
120Hz
Pair or Single
Single
Grill Included
NO

Motor

Voice Coil Diameter
1" / 25mm
Voice Coil Former Material
KSV
Winding Material
CCAW
Cone Material
Paper
Bullet Material
High temperature resistant ABS
Bullet Color
Black Matte
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Black Matte
Magnet Material
Ferrite
Magnet Weight
14.4 Oz

Thiele & Small Parameters

Equivalent Volume Vas
5.86L / 0.207ft3
Excursion (one way) Xmax
3mm
Free Air Resonance Fs
144Hz
Mechanical Factor Qms
10.49
Electrical Factor Qes
2.183
Total Factor Qts
1.807
Mechanical Mass Mms
5.98g
Mechanical Compliance Cms
201.495m/N
BL Factor BL
2.87
Voice Coil Inductance Le
0.16mH
Cone Area Sd
132Cm2
DC Resistance Re
3.3 Ω
Mechanical Mass w/o air Mmd
5g

Measurement

Overall Diameter
6.46" / 164mm
Overall Depth
2.8" / 71mm
Front Mount Baffle Cutout
5.8" / 147mm
Mounting Depth
2.56" / 65mm
Motor Diameter
3.54" / 90mm
Gross Single Unit Weight
1kg
Single Unit Box Dimensions W x L x H
183 x 175 x 86mm
Quantity of Units in Master Carton
12pcs
Gross Master Carton Weight
12kg
Master Carton Dimensions W x L x H
38 x 27.3 x 37cm

Product Overview

DS18 PRO-B6.4

6.5” Mid-Range Car Audio Loudspeaker with Bullet 120W 4-Ohm

DS18’s PRO-B6.4 is engineered to redefine your idea of mid-range frequency audio reproduction.
The PRO-B6.4 is a true powerhouse that will take your audio system to new heights with RMS power handling of 60W and a MAX power handling of 120W. Its strong ferrite magnet ensures that every powerful piece of equipment is held together, allowing you to unleash the full potential of your car's audio system. With its exceptional design and cutting-edge technology, this 6.5" speaker is meticulously crafted to deliver an unrivaled sound experience that will leave you spellbound.
One of the standout features of the PRO-B6.4 is its remarkable 93.4 dB sensitivity, allowing you to push the boundaries without fear of distortion or loss of quality. Immerse yourself in the exhilarating music experience you've always dreamed of, as every note and detail is brought to life with unparalleled clarity.
Designed for the true audiophile, the PRO-B6.4 has an impressive frequency response range of 100Hz to 12.5KHz, guaranteeing an incredible range of tones and frequencies that will satisfy even the most discerning ears. From deep, soul-stirring bass to sparkling high notes, every nuance is reproduced with astonishing precision. Immerse yourself in the music you love and rediscover your favorite tracks like never before.
Rigorously tested and built to withstand intense jam sessions, the PRO-B6.4 ensures uncompromising durability. With a 1” high-powered voice coil, no matter how high you crank up the volume, the PRO-B6.4’s will stay true to their promise of delivering crystal-clear, distortion-free sound.
