INFINITE 55 AH AGM Power Cell Battery

SKU: INF-55AH
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery
INFINITE 55 AH AGM Power Cell Battery

INFINITE 55 AH AGM Power Cell Battery

SKU: INF-55AH

Sale price$257.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock

Channel:

Power Rating:

:

:

Color:

Quantity:
  • Key Features

    • 12 Volt AGM Battery
    • 55 AMP Hours
    • Thread Lead Alloy Recessed / M6 Bolt
    • Maintenance Free
    • 1750 Power Watts
    • Made in Vietnam
  • Technical Data - Manual

    SPECS

    SKU
    INF-55AH
    Battery Type
    AGM
    Nominal Voltage
    12.8 V
    Capacity
    55Ah @ 10hr-rate to 1.8V per cell @ 25°C (77°F)
    Maximum Discharge Current
    1650 Amps
    Cranking Amps (CA)
    825 Amps
    Cold Cranking Amps (CCA)
    400 Amps
    Spillable
    Non Spillable

    OTHER SPECS

    Watts (RMS)
    1750W
    Internal Resistance
    Approx. 6.5 mΩ
    Float Charging Voltage
    13.5 to 13.8 Vdc / unit average at 25°C (77°F)
    Recommended Charging Current
    16.5 Amps
    Nominal Operating Temperature Range
    25°C +/- 3° (77°F +/- 5°)
    Bolt / Terminal Type
    Thread Lead Alloy Recessed / M6 Bolt
    Battery Group U1
    Thread Lead Alloy Recessed / M6 Bolt
    Made In
    Made In Vietnam

    MEASUREMENT

    Overall Length
    9" / 230mm
    Overall Width
    5.43" / 138mm
    Overall Height
    8.46" / 215mm
    Overall Height (Without Terminals)
    8.26" / 210mm
    Weight
    36.30 Lbs / 16.5 kg
    Product Weight
    37.5 lbs
    Product Dimensions
    10 x 6 x 10.25
    M/C Weight
    37.5 lbs
    M/C Dimensions
    10 x 6 x 10.25
    M/C QTY
    1
    Sold In
    Piece

    Load More
  • Product Overview

    Product Overview

    DS18 INF-55AH

    INFINITE 1750W 55AH AGM Power Cell 12V

    DS18’s INF-55AH is a high-performance AGM power cell designed to push car audio systems to the limit. Built with Absorbed Glass Mat (AGM) technology, this battery ensures consistent voltage delivery, reliable reserve power, and high-amperage bursts.

    Powers Systems Up to 1750W
    With a high burst reserve and consistent voltage retention, the INF-55AH powers up high-amperage systems while maintaining stability—making it ideal for competition-level builds and high-wattage daily setups.

    Mount It Anywhere
    Designed with a non-spill, sealed design, this power cell can be mounted upside down or in multiple positions for flexibility during tight installations without the risk of leaking.

    Bolt M5 Terminals
    The M5 bolt terminals provide a secure connection while allowing for easy integration of additional terminals and busbars for enhanced conductivity and improved power distribution.

    More Voltage
    With a high float charge, the INF-55AH keeps your voltage high, lights bright, and electronics running smoother—whether you're pushing peak power or maintaining steady performance.

    For serious power, trust DS18 for LOUD and reliable performance.

    Disclaimer: Mount batteries away from heat sources. Do not install near engine bays—risk of swelling, especially in hot climates. Use cabin, trunk, or bed locations only.
