DS18 G3600.4D Full-Range Class D 4-Channel Car Audio Amplifier 3600 Watts

The Gen-X series has always been a DS18 staple with the public and been in countless system builds over the many years it was released.

We have completely redesigned the GEN-X series from the ground up to meet and audio enthusiasts high standards and complete their goals for the system of their dreams with great power, reliability, and efficiency.

The G1800.4D has a power rating of 4x300 watts RMS at 4 ohms 4x420 RMS at 2 ohms, 2x740 at 4 ohm bridge, and 3600 MAX at the two load it was designed for, giving you pure and clean power on demand.

This amp has the power to drive your speakers but also not take up much space because of the new compact design and technology that will keep your amp playing cool and loud.

Highlights

  • Small and powerful design so you can power your subs with great efficiency and power without taking up much space
  • Integrated low pass and high pass filter to help you get the perfect response you are looking for.
  • High quality terminals that look great and will transfer your power and signal with no loss.


Key Features

  • Digital Class D 4 Channel Amplifier
  • MAX Wattage: 3600w Peak
  • RMS Wattage: 2x740 Watts RMS @ 4 ohm bridge, 4x420 Watts RMS @ 2 ohms, 4x300 Watts RMS @ 4 ohms
  • Frequency Response: 20Hz-20KHz
  • Signal to Noise Ratio: >93dB
  • Efficiency at 4 ohms: 90%
  • Total Harmonic Distortion: 0.01%
  • Input Range: .25-6v
  • Selectable X-over: LPF, HPF. Flat
  • Phase: 0-180
  • Power and Ground Terminal: 4 GA
  • Minimum Impedance: 2 ohm


Great For:

  • Car Audio
  • Pro Audio
  • Motorcycles
  • Hi-Fi installation
  • Off-Road
  • DIY Projects

                                                    G3600.4D Product Manual
SPECIFICATIONS
POWER
Total Watts (Peak) 3600W
RMS Power @ 4 ohm 4 x 300W
RMS Power @ 2 ohm 4 x 420W
RMS Power @ 4 ohm Bridge 2 x 740W
AUDIO
Frequency Response 20Hz-20KHz
Signal to Noise Ratio >93dB
Efficiency @ 4ohm 80%
Damping Factor 78
Input Impedance 22K
Channel Separation 70dB
Total Harmonic Distortion (THD) 0.01%
Low Level Input Range 0.25-6V
High Level Input NO
Selectable X-Over LPF/FLAT/HPF
X-Over Filter Range 50 - 250Hz
Bass Boost Range N/A
Bass Boost Frequency N/A
Infrasonic Filter N/A
Phase Selector NO
FEATURES
Amplifier Class Digital (D)
Amplifier Type 4CH Full Range
Number of Channels 4CH
Minimum Impedance 2 ohm St / 4 ohm Bridge
Led Indicator Power / Protection / Clip
Power Input Terminal Size 4ga
Fuse Size 3 x 40A
Remote Level Control NO
Cooling Fan NO
Voltmeter  NO
Thermal Protection YES
Over-Load Protection YES
DC Output Protection YES
Short Circuit Output Protection YES
Voltage Input Protection YES
Clipping Protection  YES
Body Color / Finish Matte black
MEASUREMENT
Overall Length 12" / 305mm
Overall Wide 4.72" / 120mm
Overall Height 1.96" / 50mm
Heatsink Length  10.15" / 258mm
Gross Single Unit Weight 1.9KG
