PRO 6.5” Slim Professional Mid-Range Speaker With Neodymium Magnet 180 Watts Rms 8-Ohm - Recommended for Dome and Diffuser Horn (LA)

PRO 6.5” Slim Professional Mid-Range Speaker With Neodymium Magnet 180 Watts Rms 8-Ohm - Recommended for Dome and Diffuser Horn (LA)

Name: PRO 6.5” Slim Professional Mid-Range Speaker With Neodymium Magnet 180 Watts Rms 8-Ohm - Recommended for Dome and Diffuser Horn (LA)
Brand: 6PRO360NSL-8
SKU: 6PRO360NSL-8
Price: 149.95 USD
Availability: InStock

SKU: 6PRO360NSL-8

$149.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

6.5" Square Slim Mid-Range
MAX Power: 360 Watts
RMS Power: 180 Watts
Impedance: 8 Ohm
Neodymium Magnet
103dB

In stock

Channel:

Power Rating:

Color:

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

6.5" DIAMETER

MID-RANGE

8 OHM

NEODYMIUM MAGNET

Shallow

1.78" Interleaved Sandwich Voice Coil (ISV)

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

SPECS

SKU
6PRO360NSL-8
Nominal Diameter
6.5" / 165mm
Nominal Impedance
8 Ohms
RMS Power Handling
180W
MAX Power Handling
360W
Sensitivity (1w/1m)
103dB
Frequency Response
100Hz-10KHz
Recommended HI Pass Crossover
120Hz
Sold in Pair or Single
Single
Grill Included
No

Features

Interleaved Sandwich Voice coil (ISV)
Yes
Demodulating Rings
No
Improved Heat Dissipation
Yes
Cone Shape
Curvilinear
Speaker Terminals
Push (12ga)

Motor

Voice Coil Diameter
1.78" / 45mm
Voice Coil Former Material
Fiberglass
Winding Material
Aluminum
Cone Material
Non-Pressed Paper
Dust Cap Material
Cloth
Bullet Material
N/A
Bullet Color/Finish
N/A
Surround Material
Cloth
Basket Material
Die-Cast Aluminum
Basket Color/Finish
Black
Magnet Material
Neodymium
Magnet Weight
11.7 Oz
Displacement Volume
-

Thiele & Small Parameters

Equivalent Volume Vas
11.54L / 0.4ft3
Excursion (one way) Xmax
2.5mm
Free Air Resonance Fs
125Hz
Mechanical Factor Qms
8.76
Electrical Factor Qes
0.53
Total Factor Qts
0.5
Mechanical Mass Mms
4.68g
Mechanical Compliance Cms
0.34 mm/N
BL Factor BL
6.53
Voice Coil Inductance Le
0.68mH
Cone Area Sd
153.94 Cm2
DC Resistance Re
5.9 Ohms
Mechanical Mass w/o air Mmd
-

Measurement

Overall Diameter
6.38" / 162mm
Overall Depth
2.44" / 62mm
Front Mount Baffle Cutout
5.82" / 148mm
Mounting Depth
2" / 51mm
Motor Diameter
3.74" / 95mm

Product Overview

DS18 6PRO360NSL-8

DS18’s 6PRO360NSL-8 is a powerhouse of sound designed to make building your system easier than ever before.

With a sleek black die-cast aluminum basket with outer support rings for organization, this midrange speaker was designed for show quality performance. The push speaker terminals (12ga) make installation a breeze, ensuring a secure and seamless connection.

Featuring a nominal impedance of 8 OHM and a robust RMS power handling of 180W, DS18’s 6PRO360NSL-8 guarantees every note, beat, and vocal is reproduced accurately. The103 dB sensitivity guarantees crystal-clear sound at high volumes so you never have to stop getting LOUD!

Equipped with an Interleaved Sandwich Voice Coil (ISV) and improved heat dissipation, this speaker can handle the most demanding audio setups. The curvilinear cone shape plays a big factor in this speaker's exceptional sound reproduction capabilities. Designed for Line Array (LA) Systems, this loudspeaker fits horn diffusers like DS18's PRO-SDF6 perfectly!

Crafted with premium materials, the DS18 6PRO360NSL-8 is built to last. Its fiberglass voice coil with a diameter of 1.78", winding material made of aluminum, and neodymium magnet, weighing in at 11.7 Oz, all work together seamlessly to produce the most vibrant audio experience possible.

Unlock the true potential of your audio system with DS18’s 6PRO360NSL-8!
