PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm

SKU: PRO-X698BM
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm
PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm

PRO-X 6X9" Mid-Range Bullet Loudspeaker | 200W RMS 8-Ohm

SKU: PRO-X698BM
$83.95
/EACH
Ships Free – Dispatches Next Business Day Within the USA
With some limitations - subject to verification and order volume
In stock

Channel:

Power Rating:

Size: 6x9"

4"
4x6"
5.25"
5x7"
6.5"
6x9"
8"
10"

Impedance: 8-Ohm

4-Ohm
8-Ohm

Color:

Quantity:

  • Key Features

    • 6x9" Mid-Range W/Bullet
    • MAX Power: 400 Watts
    • RMS Power: 200 Watts
    • Impedance: 8-Ohm
    • Ferrite Magnet
    • 96dB ~ w/Grill

  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECIFICATIONS

    SKU
    PRO-X698BM
    Nominal Diameter
    6 x 9" / 152 x 228mm
    Nominal Impedance
    8 Ohm
    RMS Power Handling
    200W
    MAX Power Handling
    400W
    Sensitivity (1w/1m)
    96dB
    Frequency Response
    100Hz-12.5KHz
    Recommended HI Pass Crossover
    120HZ
    Sold in Pair or Single
    Single
    Grill Included
    Yes

    Motor

    Voice Coil Diameter
    1.5" / 38.6mm
    Voice Coil Former Material
    Kapton
    Winding Material
    CCAW
    Cone Material
    Non-Pressed Paper
    Bullet Material
    Aluminum
    Bullet Color/Finish
    Glossy Red
    Surround Material
    Cloth
    Basket Material
    Steel
    Basket Color/Finish
    Glossy Red
    Magnet Material
    Ferrite
    Magnet Weight
    27 Oz
    Displacement Volume
    0.32L / 0.011ft3

    Thiele & Small Parameters

    Equivalent Volume
    27.34L / 0.965ft3
    Excursion (one way)
    7.7mm
    Free Air Resonance
    120Hz
    Mechanical Factor
    5.342
    Electrical Factor
    0.768
    Total Factor
    0.687
    Mechanical Mass
    8.21g
    Mechanical Compliance
    0.234mm/N
    BL Factor
    6.84
    Voice Coil Inductance
    4.11mH
    Cone Area
    207.34cm2
    DC Resistance
    5.2 ohms

    Measurement

    Overall Diameter
    9.25 x 6.5" / 235 x 165mm
    Overall Diameter With Grill
    10.2 x 7.08" / 260 x 180mm
    Overall Depth
    3.5" / 88.85mm
    Overall Depth With Grill
    3.9" / 100mm
    Front Mount Baffle Cutout
    8.7 x 6" / 222 x 152mm
    Mounting Depth
    3.27" / 83mm
    Motor Diameter
    4.3" / 110mm

    Load More

  • Product Overview

    Product Overview

    6x9” Mid-Range Loudspeaker With Bullet

    DS18’s PRO-X698BM brings unparalleled clarity to your car audio experience. These speakers set the gold standard for 6x9 car speaker upgrades.

    DS18’s PRO-X698BM has been engineered to deliver loud and powerful music without distortion. Its superior specs allow you to feel the intensity of a live concert from the comfort of your driver's seat. With an astounding 200W RMS power handling and a peak of 400W, you can push the limits of LOUD without sacrificing your quality.

    The attention to detail in construction speaks volumes; non-pressed paper cones paired with cloth surrounds are carefully housed in a steel basket, finished with a glossy red that makes a statement before the sound even hits. The included grille not only adds protection but also matches the overall design perfectly. The design features a 1.5” / 38.6mm 8 ohm voice coil made from Kapton, capable of withstanding high temperatures, guaranteeing longevity and consistent performance during the longest sessions. With a mounting depth of 3.27”, this speaker is ready to drop in on a wide range of applications.

    The PRO-X698BM features a high sensitivity of 96dB, allowing it to operate efficiently by converting power into clear, audible sound without a hint of distortion—even at extreme volume levels. With a frequency response spanning from 100Hz to 12.5KHz, every note is delivered with depth.

    By choosing the PRO-X698BM, you're investing in years of distortion-free audio that makes every drive unforgettable.

    Grille Included.
