NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm

SKU: NXL-X1500.1FR
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm
NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm

NXL 1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 Watts Rms @ 1-Ohm

SKU: NXL-X1500.1FR

Sale price$549.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock
Quantity:
  • Key Features

    • Marine Full Range
    • 1 Channel
    • 1 X 1500 Watts @ 1 Ohm
    • Built in Crossover
    • Class D
    • Water Resistant IP67
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECS

    SKU
    NXL-X1500.1FR
    Total Watts (Peak)
    3000W
    RMS Power @ 4 ohm
    1 X 700W
    RMS Power @ 2 ohm
    1 X 1000W
    RMS Power @ 1 ohm
    1 X 1500W

    AUDIO

    Frequency Response
    10Hz-250Hz
    Signal to Noise Ratio 1W @ 4?
    >81dB
    Efficiency @ 4 ohm
    92%
    Input Impedance
    20K OHM
    Total Harmonic Distortion (THD)
    <0.05%
    Low Level Input Range
    200mV-5V
    Selectable X-Over
    Band-Pass
    X-Over Filter Range
    LPF: 50Hz-20KHz / HPF: 10Hz-500Hz
    Bass Boost Range
    0-18dB
    Bass Boost Frequency
    42Hz
    Phase Selector
    0-180

    FEATURES

    Amplifier Class
    Digital
    Amplifier Type
    Full Range
    Number of Channels
    1
    Minimum Impedance
    1 Ohm
    Led Indicator
    Power | Protection | Clip
    Power Input Size
    4GA Tinned OFC
    Fuse Size
    150A
    Thermal Protection
    Yes (75C)
    Over-Load Protection
    Yes
    Short Circuit Output Protection
    Yes
    Voltage Input Protection
    Yes (7-16V)
    Body Color | Finish
    Black Brushed Aluminum

    EXTRA FEATURES

    Waterproof Rating
    IP67
    UV / Salt Fog Protection
    Yes
    Direct Power Harness Design
    Yes
    Quick Connect Plug
    Yes
    Surface Mount Component Technology
    Yes
    Marine Grade Fuse Holder
    Yes

    MEASUREMENTS

    Overall Length
    13.4" / 341mm
    Overall Wide
    4.4" / 112mm
    Overall Height
    1.77" / 45mm
    Heatsink Length
    11.8" / 301mm
    Gross Single Unit Weight
    2.7kg

    Load More
  • Product Overview

    Product Overview

    DS18 NXL-X1500.1FR

    1-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 1 x 1500 W RMS @ 1-Ohm

    Elevate your marine sound experience to new heights with DS18's NXL-X1500.1FR. Designed to deliver the best performance for your marine speakers, this digital class amplifier is the ultimate choice for those who refuse to settle for anything less than exceptional.
    Featuring an innovative Input Selector, this amplifier allows you to effortlessly choose between multiple signal sources. This flexibility ensures that you can easily customize your audio setup according to your preferences. This amplifier’s Full Range Capabilities also gives users the options of powering either subs, or mids and highs.
    Not only does DS18's NXL-X1500.1FR deliver unparalleled performance, but it also boasts an IPX6 Waterproof Rating, providing protection against water intrusion. Additionally, this amplifier is built to withstand harsh marine conditions with its UV, Salt, and Fog protection. It's designed to endure whatever nature throws at it without compromising on sound quality.
    With its Direct Power harness design featuring marine-grade OFC tinned wires, this amplifier ensures optimal power transfer and efficiency. We’ve also included a 150A Fuse to protect you and your boat from almost any electrical short related to the amp's installation. Every detail has been carefully crafted to provide you with a seamless and hassle-free installation process.
    Experience the future of marine amplification with the latest digital amplifier design and SMC technology, including both high pass and low pass filters for the one output channel. This band pass filter system enhances audio clarity and precision, allowing you to enjoy every note with exceptional clarity and detail.
    Prepare to be blown away by the NXL-X1500.1FR's staggering performance, delivering 700W RMS at 4-ohms, 1000W RMS at 2-ohms, and 1500W RMS @ 1-ohm. These power settings are guaranteed to supercharge any custom marine build.
    Don't settle for mediocre sound on your boat or powersport vehicle. Upgrade to the DS18 NXL-X1500.1FR Marine & Powersports Digital Amplifier and unleash the true potential of your marine speakers.
