1.3" Multi-Mount PEI Mini Dome Tweeter with 0.8" Voice Coil

1.3" Multi-Mount PEI Mini Dome Tweeter with 0.8" Voice Coil

Name: 1.3" Multi-Mount PEI Mini Dome Tweeter with 0.8" Voice Coil
Brand: SQT1
SKU: SQT1
Price: 39.95 USD
Availability: InStock

SKU: SQT1

NEW ARRIVAL

$39.95

/PAIR

Ships Free Next Business Day From Miami, FL, USA

1.3" Mini Dome Tweeter
RMS Power: 30 Watts(60 Watts Peak)
Impedance: 4 Ohm ~ 92dB
Neodymium Magnet
Flat ~ Angle ~ Flush Mounts
Pair

Only 10 units left

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

4 OHM

Voice Coil Diameter 0.8"

NEODYMIUM MAGNET

PEI dome DIAPHRAGM

MULTIPLE MOUNTING OPTIONS

Sold as pairs

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

General Specifications

SKU
SQT1
Nominal Diameter
1.3" / 33mm
Nominal Impedance
4 ohms
AES Power handling
15W
Program Power handling
30W
Peak Power handling
60W
Sensitivity (1w/1m)
92dB
Frequency Response
1KHz-20KHz
Recommended HI Pass Crossover
3KHz
Pair / Single
Pair
Body Color / Material
Black / ABS

Motor

Voice Coil Diameter
0.8" / 20.4mm
Voice Coil Former Material
KSV
Winding Material
Copper
Diaphragm Material
PEI
Magnet Material
Neodymium (N38H)
Magnet Weight
1.16 Oz

Measurements

With Flush Mount Adapter
Overall Diameter: 1.75" / 45mm
Overall Depth: 1" / 25mm
Front Mount Baffle Cutout: 1.6" / 40mm
Mounting Depth: 0.75" / 20mm

With Angle Surface Mount Adapter
Overall Diameter: 1.3" / 33.5mm
Overall Height: 1" / 26.7mm

Without adapter
Overall Diameter: 1.3" / 33.5mm
Overall Height: 0.96" / 24mm

Product Overview

SQT1

1.3" Multi-Mount PEI Mini Dome Tweeter with 0.8" Voice Coil

Boost your system’s clarity with the SQT1, the epitome of high-frequency clarity and versatility!

This 1.3" Multi-Mount PEI Mini Dome Tweeter balances power and precision, for crisp, accurate sound reproduction across an extended frequency range from 1KHz to 20KHz. Now available in pairs, each tweeter delivers 15W AES, 30W Program, and 60W Peak Power, making it a powerhouse addition to any setup.

Built with premium PEI and ABS materials, this high-frequency tweeter offers lasting durability and reliable performance in any environment. Featuring a sensitivity of 92 dB at 1W/1M and a 4-ohm impedance, it delivers crisp, superior highs. Equipped with a powerful yet lightweight neodymium magnet, the SQT1 enhances sound without adding bulk to your setup.

With three easy mounting options—flush, angled, and direct—installation is effortless. Perfect for car audio, the SQT1 mini dome tweeter seamlessly adapts to any setup. Unlike other tweeters, its premium build and advanced design deliver unmatched, refined treble.

Upgrade to the SQT1 today for extraordinary sound quality on every journey!
