DS18 PRO-GM6.4 6.5" Mid-Range Loudspeaker 480 Watts 4-Ohm

DS18 PRO-GM6.4 6.5" Mid-Range Loudspeaker 480 Watts 4-Ohm

Name: DS18 PRO-GM6.4 6.5" Mid-Range Loudspeaker 480 Watts 4-Ohm
Brand: PRO-GM6.4
SKU: PRO-GM6.4
Price: 27.95 USD
Availability: InStock
Rating: 5.0 (4 reviews)

SKU: PRO-GM6.4

$27.95

/EACH

Ships Free Next Business Day From Miami, FL, USA

6.5" Mid-Range
MAX Power: 480 Watts
RMS Power: 140 Watts
Impedance: 4-Ohm
Ferrite Magnet

In stock

Quantity:

Notify Me When Available

FAST FREE SHIPPING

30-DAY RETURNS

2 YEAR WARRANTY

SECURE PAYMENT

Have a Question?

Our experts are here to answer any questions you may have.

Contact Us
305-928-8734

Live Chat

KEY FEATURES

6.5" DIAMETER

MID-RANGE

4 OHM

FERRITE MAGNET

PAPER CONE

STEEL BASKET

TECHNICAL DATA

DOWNLOAD THE USER MANUAL

Specifications

SKU
PRO-GM6.4
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
4 Ohm
RMS Power Handling
140W
MAX Power Handling
480W
Sensitivity (1w/1m)
92dB
Frequency Response
100Hz-10KHz
Recommended HI Pass Crossover
120Hz
Pair or Single
Single
Grill Included
No

Motor

Voice Coil Diameter
1.5" / 38.1mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
Paper
Bullet Material / Color
N/A
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Matte Black
Magnet Material
Ferrite
Magnet Weight
23 oz

Thiele & Small Parameters

Equivalent Volume (Vas)
7.15L / 0.252ft3
Excursion (one way) (Xmax)
N/A
Free Air Resonance (Fs)
102Hz
Mechanical Factor (Qms)
11
Electrical Factor (Qes)
0.729
Total Factor (Qts)
0.684
Mechanical Mass (Mms)
8.384g
Mechanical Compliance (Cms)
0.289mm/N
BL Factor
4.95
Voice Coil Inductance (Le)
0.411mH
Cone Area (Sd)
132.73cm2
DC Resistance (Re)
3.3 ohm

Measurement

Overall Diameter
6.57" / 167mm
Overall Depth
2.7" / 69mm
Front Mount Baffle Cutout
5.7" / 145 mm
Mounting Depth
2.5" / 64mm
Motor Diameter
4.33" / 110mm
Gross Single Unit Weight (lb)
4
Single Unit Box Dimensions W x L x H (Inches)
7.3 x 7.3 x 3.25
Quantity of Units in Master Carton
8
Gross Master Carton Weight (lb)
32
Master Carton Dimensions W x L x H (Inches)
15.25 x 15.25 x 7.5

Product Overview

DS18 PRO-GM6.4

6.5" Mid-Range Loudspeaker 480 Watts 4-Ohm

Experience the thrill of crystal-clear sound and heart-pounding bass with DS18’s PRO-GM6.4!
This remarkable mid-range loudspeaker is the latest rendition of our highly acclaimed PRO-GM6 speaker, but with a twist. We've upgraded it to 4 ohms, creating a speaker that pushes boundaries like never before. These speakers deliver an audio experience that transcends expectations, delivering unparalleled performance and precision.
With an impressive RMS power handling of 140W and a maximum power rating of 480W, the PRO-GM6.4 stands as one of the most potent mid-range loudspeakers in our catalog. Its wide frequency range of 98Hz to 10kHz ensures that every note is reproduced with astonishing accuracy.
The PRO-GM6.4 is tailored for those who demand nothing short of perfection from their 6-inch speakers. Featuring non-pressed paper cones and steel pressed frames, these speakers boast exceptional durability and reliability. The 30oz ferrite magnet provides a solid foundation, allowing the PRO-GM6.4 to handle even the most intense audio demands with ease.
One of the standout features of the PRO-GM6.4 is its sealed back design. This innovative design allows you to confidently install these speakers in boxes with high turbulence or pressure without fear of damaging the cones. Whether you prefer stunt walls or chuchero boxes with mid-bass or bass speakers, the PRO-GM6.4 seamlessly integrates into and enhances your existing audio setup, taking it to unprecedented levels of performance.
Immerse yourself in the music, feel the vibrations in your chest, and let the PRO-GM6.4 transport you to new dimensions of sound.

Put on motorcycle

I did a waterproof spray sealer on these speakers. I have a cheap Pyle marine double din radio powering these speakers sound great. Tried with a small amp sounded even better no distortion what so ever. Nice clear sound they hit when the need to. Happy with this product will being doing more business with DS18 in near future.
