DS18 JP6NEO.FR Plug and Play Dash Enclosure Upgrade with 6.5" Neo Full-Range Loudspeaker for Jeep JL/JLU and JT Left and Right

As the most popular manufacturer of professional grade Jeep Audio products, DS18’s expert engineering team is still in search of ways to enhance their previous designs.

Neodymium magnets are the strongest and lightest magnets commercially available today. The JP6NEO.FR is furnished with high strength neodymium midrange speakers, the PRO-FR6NEO, for an expansive covering of the midrange frequencies.

Protected by a high-strength aluminum basket, these speakers are sure to outlast your vehicle. The speakers included with the JP6NEO.FR offer extreme volumes at a lower power requirement than other mid-range loudspeakers. They also come equipped with a Silver Bullet Phase Plug that helps efficiency throughout. These neodymium powerhouses are sure to give crisp clear highs with a power rating of 225 watts RMS and 450 watts MAX power @ 4 Ohms.

This pair of easy to install enclosures come with everything you need to get amazing sound out of your front stage! Plug this enclosure directly into your existing wiring harness, connect directly to your factory amplifier, or add an external amplifier for extreme power and maximum loudness immediately!

Highlights

  • Plug and Play capabilities for instant installation
  • Especially designed for Jeep JL, JLU, and JT plug and play installation.
  • The units use the factory amplifier but alternatively can be powered for even more volume with an external amplifier.
  • 6.5” DS18 Pro-FR6NEO Pro Audio Mid-Range Loudspeaker included for the loudest sound and highest wattage to decibel efficiency 225 watts RMS 450 watts MAX @ 4 Ohms. (pair)
  • Silver Bullet Resonator (tweeter) that offers the higher range of your NEO bringing you a fuller range of frequencies to blast.

Great For

  • Jeep Audio

General Specifications





Nominal Speaker Diameter



6.5" / 165mm

Nominal Impedance



4 Ohms

RMS Power Handling



225W

MAX Power Handling



450W

Sensitivity (1w/1m)



97dB

Frequency Response



100Hz-16KHz

Recommended HI Pass Crossover



160Hz

Sold in Pair or Single



Pair (Left & Right)







Body / Features





Enclosure Material



ABS Injected Plastic

Wiring / Connections



OEM Plug Connector

Clamps



ABS Factory Location

Finish



Satin Black







Woofer Specifications





Voice Coil Diameter



1.5" / 38.6mm

Voice Coil Former Material



Kapton

Winding Material



CCAW

Cone Material



Non-Pressed Paper

Dust Cap Material



N/A

Bullet Material / Color



Silver Aluminum

Surround Material



Cloth

Basket Material



Aluminum

Magnet Material



Neodymium

Magnet Size / Weight



90x6mm / 7.67 Oz







Thiele & Small Parameters





Equivalent Volume

Vas

2.11L / 0.074ft3

Excursion (one way)

Xmax

6.8mm

Free Air Resonance

Fs

166Hz

Mechanical Factor

Qms

3.173

Electrical Factor

Qes

0.409

Total Factor

Qts

0.362

Mechanical Mass

Mms

11.31g

Mechanical Compliance

Cms

0.08mm/H

BL Factor

BL

9.79

Voice Coil Inductance

Le

0.472mH

Cone Area

Sd

136.85cm2

DC Resistance

Re

3.3 ohm

Mechanical Mass w/o air

Mmd

/







Enclosure Measurement





Overall Length (Left)



7.5" / 190mm

Overall Depth (Left)



7.38" / 187mm

Overall Height (Left)



10.47" / 265mm

Overall Length (Right)



8.18" / 207mm

Overall Depth (Right)



8.14" / 206mm

Overall Height (Right)



9.96" / 252mm








Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
J
J.F.
Loud & Crisp

With these speakers, DS18 lives up to it motto of, “We Like It Loud.” The sound is crisp, loud and when that down beat hits, you feel it! The speaker boxes themselves were spot on in regard to fit and Plug-and-Play.

My only negative comment I will give is with the driver side speaker box. For the JL Wrangler there is a box from the OEM speakers which needs to be mounted into the back of the DS18 and the speakers have those mounting points however, the locations provide are not threaded.

I called customer service and their advice is to have a second person hold the pieces in place while I DRILL the (1/8”) hole. I obviously had to do it but was a bit taken aback that DS18 would not have this done during assembly.

R
Rachael Wilkes
Great sound

Changed out my dash speakers to these and it’s a clear difference. I didn’t add an amp or anything else and it still improved the sound. There’s definitely more push from the front whereas before it seemed I didn’t have much sound coming from them. I’ve got the DS18 soundbar already, I’ll be adding more soon.
