8-Channel In and 8-Channel Out Digital Sound Processor (DSP) with Bluetooth

SKU: DSP8.8BT
DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth.
DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth.
DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth.
DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth.
DS18 DSP8.8BT 8-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth.

8-Channel In and 8-Channel Out Digital Sound Processor (DSP) with Bluetooth

SKU: DSP8.8BT

Sale price$329.95
/EACH
Ships Free Next Business Day From Miami, FL, USA
With some limitations - subject to verification and order volume
In stock

Channel:

Power Rating:

:

:

Color:

Quantity:
  • Key Features

    • Digital Sound Processor
    • 8 Channel In
    • 8 Channel Out
    • Remote Output
    • Bluetooth Connectivity Via App
    • IOS and Android Compatible
  • Technical Data - Manual

    DOWNLOAD THE USER MANUAL

    SPECIFICATIONS

    POWER SUPPLY

    Working Voltage
    9 - 16 VDC
    Remote Input Voltage
    9 - 16V
    Remote Output Voltage
    12.8V (0.5A)
    Fuse Size
    2 Amp
    DSP Speed
    147 MIPS
    DSP Precision
    32-Bit
    DSP Accumulators
    72-Bit

    AUDIO

    THD + N
    < 1%
    Frequency Response
    20Hz-20KHz (+/- 0.5dB)
    Signal to Noise Ratio @ A Weighted
    >100dB
    Input Sensitivity
    0.2 - 9V
    Input Impedance
    20kΩ
    Maximum Pre-Out Level (RMS)
    8V
    Pre-Out Impedance
    200Ω

    AUDIO ADJUSTMENT

    Crossover Frequency
    Variable HPF/LPF 20Hz to 20KHz
    Crossover Slope
    Selectable 6/12/18/24/36/48 dB/Oct
    Equalization
    31 Bands Parametric
    Q Factor
    Selectable 0.05 to 20
    EQ Presets
    Yes POP/Dance/Rock/Classic/Vocal/Bass
    User Presets
    Yes Basic / Advanced

    DIGITAL TO ANALOG CONVERSION (DAC)

    Precision
    24-Bit
    Dynamic Range
    108dB
    THD + N
    -98dB

    ANALOG TO DIGITAL CONVERSION (ADC)

    Precision
    24-Bit
    Dynamic Range
    105dB
    THD + N
    -98dB

    INPUT | OUTPUT

    High / Low Level Input
    Up to 8 channel
    Low Level Output
    Up to 8 Channel
    Type
    RCA (Female)

    DIMENSIONS / SHIPPING INFO

    Length
    6.37" / 162mm
    Depth
    3.6" / 91.5mm
    Height
    1.24" / 31.7mm
    Dimensions Single Box L x W x H (Inches)
    8 x 4.75 x 3.25
    Weight (lb)
    1
    M/C Dimension L x W x H (Inches)
    17 x 14 x 15
    M/C Weight (lb)
    30
    M/C Qty
    24 Pcs

    Load More
  • Product Overview

    Product Overview

    DS18 DSP8.8BT

    8-Channel In / 8-Channel Out Digital Sound Processor with Bluetooth

    If you’re serious about car audio and want to dial in the audio reproduced by your components use DS18’s DSP8.8BT: your system’s new command center.

    Total Control
    The DSP8.8BT gives you full 8-in/8-out signal control with pro-grade tools right out of the box. You’ve got a 31-band graphic EQ, fully adjustable crossovers (6–48dB/octave), delay, phase control, gain tweaks—everything you need to get that perfect balance.

    App-Tuned
    Control everything wirelessly through the DSP8.8BT App for iOS or DSP8.8BT App for Android. Set it from your driver’s seat. Dial in your front stage, rear fill, and sub timing in real-time. Save custom presets for your favorite genres or switch between tuning setups with a tap.

    Tuned By You, For You
    Want more punch in your vocals? This processor gives you surgical-level precision so you can tweak your sound exactly how you like it. Save 10 presets and instantly switch between them depending on what you’re listening to.

    Absolute Unit
    You’re working with 32-bit DSP processing, real-time data sync, high-voltage RCA outputs (up to 8V), and a smooth Bluetooth connection. No matter what you’re running, this unit can handle it.
